Overview

Features and Benefits

  • High-Efficiency Switching Charger Tailored for Small Capacity Batteries Saves Space, Extends Battery Life
  • Battery Isolation Switch Extends Battery Shelf Life
    • Hardware/Software Configurable
    • Integrated Power-Key Monitor
  • Integration Simplifies and Shrinks Display Driving Circuitry
    • 3-Channel Programmable-LED Current Sinks
    • Integrated Step-Up Converter
  • Integrated Protection and Control for Reliable Performance
    • Fully Integrated Cable Detection Controller to Ensure Measurement Accuracy
    • Overvoltage and Thermal Protection
      • 28V Tolerant VB Input Connection
    • High ESD Protection (VB, DP, DM, Active-Low KIN)
      • ±15kV HBM ESD Protection
      • ±10kV Air-Gap Protection
      • ±8kV Contact Discharge Protection
    • Manual Reset Controller
    • Programmable Interrupt Generation (I2C)
  • Integrated ModelGauge Host-Side Fuel Gauge Saves Space and Accurately Estimates State of Charge
    • ModelGauge Algorithm
    • Tolerates Temperature & Load Variation
    • No Error Accumulation
    • Learning Not Necessary
    • Current-Sense Resistor Not Required

Product Details

The MAX14663 is a complete power solution for portable medical devices, including blood glucose meters.

The device integrates a high-efficiency single-cell Li-ion switching charger targeted at space-limited portable applications with small batteries.

An ultra low-power seal mode which significantly reduces standby current and preserves battery charge during prolonged periods of storage is also included. This mode extends battery shelf life, and enables improved customer experience with immediate out-of-box use.

Additionally, the MAX14663 embeds a Maxim proprietary ModelGauge™ (fuel gauge), which provides an accurate estimate of the available capacity for rechargeable Li-ion batteries.

A boost converter and LED current sinks are also integrated for powering OLED displays or LED backlights. Internal cable-detection circuitry enables the MAX14663 to identify the presence of an unpowered/unconnected USB cable. This information can be used by the portable system to intelligently select its operating mode, maximizing accuracy and minimizing measurement errors.

The MAX14663 operates over the -20°C to +70°C temperature range and is available in a (5mm x 5mm), 40-pin, TQFN-EP package.

Applications

  • Portable Blood Glucose Meters
  • Portable Medical Devices
  • USB Connected Devices
