HMC219A

Obsolete

DBL-BAL Mixer SMT, 4.5 - 9.0 GHz

Part Models: 3
1ku List Price: price unavailable

Viewing:

Overview

Ultra Small Package: MSOP8
Conversion Loss: 8.5 dB

LO / RF Isolation: 25 dB

The HMC219AMS8(E) is an ultra miniature double-balanced mixers in an 8 lead plastic surface mount package (MSOP). This passive MMIC mixer is constructed of GaAs Schottky diodes and novel planar transformer baluns on the chip. The device can be used as an upconverter, downconverter, bi-phase (de)modulator, or phase comparator. The consistent MMIC performance will improve system operation and assure regulatory compliance.

The HMC219AMS8(E) is a replacement for the HMC219MS8(E).

Applications

UNII & HiperLAN
Microwave Radios
ISM

Suggested Replacement Parts

GaAs MMIC DBL-BAL Mixer, 3.5 - 8 GHz

Part Models: 3
1ku List Price: price unavailable

Documentation

Obsolete Data Sheet 1

HMC219A Data Sheet 09/11/2015

ADI has always placed the highest emphasis on delivering products that meet the maximum levels of quality and reliability. We achieve this by incorporating quality and reliability checks in every scope of product and process design, and in the manufacturing process as well. "Zero defects" for shipped products is always our goal. View our quality and reliability program and certifications for more information.

Part Model	Pin/Package Drawing	Documentation	CAD Symbols, Footprints, and 3D Models
HMC219AMS8	8-Lead MSOP	Material Declaration Reliablity Data Package Resources	Ultra Librarian SamacSys
HMC219AMS8E	8-Lead MSOP	Material Declaration Reliablity Data Package Resources	Ultra Librarian SamacSys
HMC219AMS8ETR	8-Lead MSOP	Material Declaration Reliablity Data Package Resources	Ultra Librarian SamacSys

Part Models	Product Lifecycle	PCN

Dec 14, 2015 - 15_0026 Discontinuance of Select Hittite Microwave Products (HMC) from Analog Devices
		PDN15_0026_Form Material_Report
HMC219AMS8	Obsolete
HMC219AMS8E
HMC219AMS8ETR
