Overview

Features and Benefits

  • Gain: 13 dB typical
  • High 1 dB compression (P1dB) output power: 29 dBm typical
  • High output third-order intercept (IP3): 40 dBm typical
  • Regulated supply and bias sequencing
  • Subminiature Version A (SMA) connectors
  • Operating temperature range: −40°C to +70°C

Product Details

The HMC-C074 is a single stage power amplifier that operates between 10 MHz and 6 GHz. The amplifier provides 13 dB of gain, 40 dBm output IP3, and 29 dBm of output power at 1 dB gain compression while only consuming 450 mA from a 15 V supply.

The ±0.75 dB gain flatness is excellent from 10 MHz to 6 GHz, making the HMC-C074 ideal for EW, ECM, radar, and test equipment applications.

The amplifier inputs/outputs are dc blocked and internally matched to 50 Ω. Integrated voltage regulators allow for flexible biasing of both the negative and positive supply pins, while internal bias sequencing and active bias control allows for robust operation and stable performance over temperature.

Applications

  • Telecom infrastructure
  • Test instrumentation
  • Military and space
  • Electronic warfare (EW)
  • Electronic countermeasures (ECM)
  • Radars
  • Test equipment

Product Lifecycle icon-not-recommended Last Time Buy

All products in this family will be obsolete soon. Please contact ADI Sales or Distributors to arrange for final purchases and read our Obsolescence Information to review the time periods for placing final orders and receiving final shipments.
