DS1088E
ObsoleteFixed-Frequency EconOscillator™
133MHz Square-Wave Generator
Viewing:
Part Details
- Factory-Programmed, 133MHz Square-Wave Generator
- Single Output
- No External Timing Components Required
- 2.85V to 3.6V Supply
- Power-Down Mode
- Wide Temperature Range (-40°C to +95°C)
The DS1088E is a low-cost clock generator that produces a square-wave output without external timing components. The fixed-frequency oscillator is available in a factory-calibrated frequency of 133MHz. The device has a power-down pin for power-sensitive applications.
Applications
- Automotive Telematics
- Cable Modems
- Computer Peripherals
- Copiers
- Optical Modules
- POS Terminals
- Printers
