Overview
Features and Benefits
- User selectable sensor g ranges:
±60 g, ±120 g, ±240 g, ±480 g - Compliant to PSI5 Version 2.1 airbag substandard
- Synchronous operation
- PSI5-P10P-500/3L and others
- Daisy-chain operation with bidirectional communication
- Synchronous operation
- Application level serial peripheral interface (SPI) communication
- Independently programmable g range and time slot for each axis
- Dual x-axis and z-axis sensor
- Selectable 16-bit or 10-bit sensor data
- Independent fault discrimination for each axis
- Fully differential analog signal chain
- 0.25 μs data interpolation routine
- User selectable, continuous auto-zero operation
- High resistance to electromagnetic interference (EMI) and radio frequency interference (RFI)
- SPI mode supply voltage: 3.3 V and 5 V, +5%
- PSI5 mode supply voltage range: 4.5 V to 11.0 V
- Qualified for automotive applications
Product Details
The ADXL252 is a dual-axis, integrated satellite sensor with user selectable g ranges, compliant to the PSI5 Version 2.1 airbag substandard, and backwards compliant to PSI5 Version 1.3. The ADXL252 (x-axis/z-axis) enables low cost solutions for front impact and side impact airbags, as well as satellite sensor and electronic control unit (ECU) main sensor applications. Acceleration data is sent to the control module via a digital, 2-wire current loop PSI5 bus. Communication via the SPI bus is also available for ECU applications.
The device uses an ECC protected one time programmable (OTP) memory. The sensor g range is configurable to provide full-scale measurement of ±60 g, ±120 g, ±240 g, or ±480 g acceleration. The user can program each axis independently with multiple g ranges in different time slots. In PSI5 mode, there are four programmable time slots available. The device transmits 16-bit or 10-bit acceleration data to the control module, and can be configured to include either a 1-bit parity check, or a 3-bit cyclic redundancy check (CRC).
The ADXL252 is available in a 4 mm × 4 mm LFCSP package and is specified to operate over the full automotive temperature range, −40°C to +125°C.
APPLICATIONS
- Front impact crash sensing
- Side impact crash sensing
Product Lifecycle
Last Time Buy
All products in this family will be obsolete soon. Please contact ADI Sales or Distributors to arrange for final purchases and read our Obsolescence Information to review the time periods for placing final orders and receiving final shipments.
