Overview

Features and Benefits

  • Extended support for HDTV input formats
  • CGMS-A Copy Protection for European 625p requirements
  • Improved SDTV Performance Improvements for Modulated Outputs

Product Details

The ADV7322 is a high speed, digital-to-analog encoder on a single monolithic chip. It includes six high speed video DACs with TTL-compatible inputs. It has separate 8-, 16-, and 24-bit input ports that accept data in high definition (HD) and/or standard definition (SD) video format. For all standards, external horizontal, vertical, and blanking signals, or EAV/SAV timing codes, control the insertion of appropriate synchronization signals into the digital data stream and, therefore, the output signal.

APPLICATIONS

  • Low-Cost Consumer Video Applications
  • DVD Players/Recorders requiring 625p CGMS-A copy protected video outputs
  • HD Video Players/Recorders
  • HD Set-Top-Boxes and iDTV
  • Professional Video Editing & Studio Equipment
  • Medical & Industrial Imaging

Product Lifecycle icon-not-recommended Not Recommended for New Designs

This designates products ADI does not recommend broadly for new designs.
