ADV7320
ADV7320
NOT RECOMMENDED FOR NEW DESIGNS12-bit 216MHz Video Encoder with NSV and Macrovision® Copy Protection
Viewing:
Part Details
- Extended support for HDTV input formats
- CGMS-A Copy Protection for European 625p requirements
- Improved SDTV Performance Improvements for Modulated Outputs
The ADV7320 is a digital-to-analog video encoder for standard definition, progressive scan and high definition video. It converts a wide variety of digital video formats into analog CVBS, S-Video, YPbPr or RGB video signals.
CGMS-A support for 625p output standards allows DVD players & recorders to comply with industry requirements for copy-protection.
The ADV7320 provides enhanced performance for SDTV and supports a range of directly supported SMPTE HDTV input standards.
Applications
- DVD Players/Recorders requiring 625p CGMS-A copy protected video outputs
- HD Video Players/Recorders
- HD Set-Top-Boxes and iDTV
- Professional Video Editing & Studio Equipment
- Medical & Industrial Imaging
Documentation
This is the most up-to-date revision of the Data Sheet.
