ADP3522

Obsolete

GSM Power Management System

Data Sheet (Rev. 0) Product Selection Table

Viewing:

Overview

Handles all GSM Baseband Power Management
6 LDOs Optimized for Specific GSM Subsystems

Li-Ion Battery Charge Function
Optimized for the AD20msp430
Baseband Chipset
Reduced Package Size: 5 mm × 5 mm
LFCSP-32

ADP3522 is a multifunction power system chip optimized for GSM/GPRS handsets, especially those based on the Analog Devices AD20msp430 system solution with 1.8V digital baseband processors such as the AD6525, AD6526, and AD6528. It contains six LDOs, one to power each of the critical GSM sub-blocks. Sophisticated controls are available for power up during battery charging, keypad interface, and RTC alarm. The charge circuit maintains slow current charging during the initial charge phase and provides an end of charge signal when a Li-Ion battery is being charged. This product also meets the market trend of reduced size with a new LFCSP package. Its foot print is only 5x5 mm, and yet offers excellent thermal performance due to the exposed die attach paddle.

ADP3522 is specified over the temperature range of -20°C to +85°C.
