ADP122

5.5 V Input, 300 mA, Low Quiescent Current, CMOS Linear Regulator, Fixed Output Voltage

Show More showmore-icon

Info: : PRODUCTION tooltip
Info: : PRODUCTION tooltip
Viewing: Part Details
arrow-icon

Not the part you were looking for?

viewall Go to Product Selection Table
file View Data Sheet (Rev.E)
Documentation View All Documentation
LTspice ADP122 - LDO Linear Regulators Download 0.79 KB
Part Models 10
1ku List Price Starting From $0.42
Features
  • Input voltage supply range: 2.3 V to 5.5 V
  • 300 mA maximum output current
  • Fixed and adjustable output voltage versions
  • Very low dropout voltage:  85 mV at 300 mA load
  • Low quiescent current: 45 μA at no load
  • Low shutdown current: <1 μA
  • Initial accuracy: ±1% accuracy
  • See Data Sheet for additional features
Additional Details
show more Icon

The ADP122 / ADP123 are low quiescent current, low dropout linear regulators. They are designed to operate from an input voltage between 2.3 V and 5.5 V and to provide up to 300 mA of output current. The low 85 mV dropout voltage at a 300 mA load improves efficiency and allows operation over a wide input voltage range.

The low 170 μA of quiescent current at full load makes the ADP122 ideal for battery-operated portable equipment.

The ADP122 is capable of 31 fixed output voltages from 1.75 V to 3.3 V. The ADP123 is the adjustable version of the device and allows the output voltage to be set between 0.8 V and 5.0 V by an external voltage divider.

The ADP122 / ADP123 are specifically designed for stable operation with tiny 1 μF ceramic input and output capacitors to meet the requirements of high performance, space constrained applications.

The ADP122 / ADP123 have an internal soft start that gives a constant start-up time of 350 μs. Short-circuit protection and thermal overload protection circuits prevent damage in adverse conditions. The ADP122 / ADP123 are available in a tiny, 5-lead TSOT package and 6-lead LFCSP package for the smallest footprint solution to meet a variety of portable applications.

APPLICATIONS

  • Digital camera and audio devices
  • Portable and battery-powered equipment
  • Automatic meter reading (AMR) meters
  • GPS and location management units
  • Medical instrumentation
  • Point-of-sale equipment
Show More Arrow image
file View Data Sheet (Rev.E)
Documentation View All Documentation
LTspice ADP122 - LDO Linear Regulators Download 0.79 KB
Part Models 10
1ku List Price Starting From $0.42
