ADN8833
Ultracompact, 1 A Thermoelectric Cooler (TEC) Driver for Digital Control Systems
Top
Overview
Features and Benefits
- Patented high efficiency single inductor architecture
- Integrated low RDSON MOSFETs for TEC driver
- TEC voltage and current operation monitoring
- No external sense resistor required
- Programmable maximum TEC voltage
- External synchronization
- Independent TEC heating and cooling current limit settings
- 2 MHz PWM switching frequency
- Digital thermal control loop compatible
- 2.50 V reference output with 1% accuracy
- Available in a 25-ball, 2.5 mm x 2.5 mm WLCSP or in a 24-lead, 4 mm x 4 mm LFCSP
Product Details
The ADN8833 is a monolithic H-bridge TEC driver with integrat-ed 1 A power MOSFETs. It has a linear power stage with the linear driver (LDR) output and a pulse-width modulation (PWM) power stage with the SW output. Depending on the control voltage at the CONT input, the ADN8833 drives current through a TEC to settle the temperature of a laser diode or a passive component attached to the TEC module to the programmed target temperature.
The control voltage applied to the CONT input is generated by a digital-to-analog converter (DAC) closing the digital proportional, integral, derivative (PID) loop of temperature control system.
The internal 2.5 V reference voltage provides a 1% accurate output that is used to bias a voltage divider network to program the maximum TEC current and voltage limits for both the heating and cooling modes. It can also be a reference voltage for the DAC and the temperature sensing circuit, including a thermistor bridge and an analog-to-digital converter (ADC).
APPLICATIONS
- TEC temperature control
- Optical modules
- Optical fiber amplifiers
- Optical networking systems
- Instruments requiring TEC temperature control
Product Categories
Markets and Technologies
Product Lifecycle
Recommended for New Designs
This product has been released to the market. The data sheet contains all final specifications and operating conditions. For new designs, ADI recommends utilization of these products.
Evaluation Kits (1)
Documentation & Resources
Design Resources
ADI has always placed the highest emphasis on delivering products that meet the maximum levels of quality and reliability. We achieve this by incorporating quality and reliability checks in every scope of product and process design, and in the manufacturing process as well. "Zero defects" for shipped products is always our goal.View our quality and reliability program and certifications for more information.
| Part Number | Material Declaration | Reliability Data | Pin/Package Drawing | CAD Symbols, Footprints & 3D Models |
|---|---|---|---|---|
| ADN8833ACBZ-R2 | Material Declaration | Reliability Data | 25-Ball WLCSP (2.54mm x 2.54mm) | |
| ADN8833ACBZ-R7 | Material Declaration | Reliability Data | 25-Ball WLCSP (2.54mm x 2.54mm) | |
| ADN8833ACPZ-R2 | Material Declaration | Reliability Data | 24-Lead LFCSP (4mm x 4mm w/ EP) | |
| ADN8833ACPZ-R7 | Material Declaration | Reliability Data | 24-Lead LFCSP (4mm x 4mm w/ EP) | |
| Wafer Fabrication Data |
