Overview

Features and Benefits

  • Differential PECL-compatible outputs
  • 700 ps propagation delay input to output
  • 75 ps propagation delay dispersion
  • Input common-mode range: –2.0 V to +3.0 V
  • Robust input protection
  • Differential latch control
  • Internal latch pull-up resistors
  • Power supply rejection greater than 85 dB
  • 700 ps minimum pulse width
  • 1.5 GHz equivalent input rise time bandwidth
  • Typical output rise/fall time of 500 ps
  • ESD protection > 4 kV HBM, >200 V MM
  • Programmable hysteresis

Product Details

The ADCMP561/ADCMP562 are high speed comparators fabricated on Analog Devices, Inc., proprietary XFCB process. The devices feature a 700 ps propagation delay with less than 75 ps overdrive dispersion. Dispersion, a measure of the difference in propagation delay under differing overdrive conditions, is a particularly important characteristic of comparators. A separate programmable hysteresis pin is available on the ADCMP562.

A differential input stage permits consistent propagation delay with a wide variety of signals in the common-mode range from −2.0 V to +3.0 V. Outputs are complementary digital signals that are fully compatible with PECL 10 K and 10 KH logic families. The outputs provide sufficient drive current to directly drive transmission lines terminated in 50 Ω to VDD − 2 V. A latch input, which is included, permits tracking, track-and-hold, or sample-and-hold modes of operation. The latch input pins contain internal pull-ups that set the latch in tracking mode when left open.

The ADCMP561/ADCMP562 are specified over the industrial temperature range (−40°C to +85°C).

Applications

  • Automatic test equipment
  • High speed instrumentation
  • Scope and logic analyzer front ends
  • Window comparators
  • High speed line receivers
  • Threshold detection
  • Peak detection
  • High speed triggers
  • Patient diagnostics
  • Disk drive read channel detection
  • Hand-held test instruments
  • Zero-crossing detectors
  • Line receivers and signal restoration
  • Clock drivers

Product Lifecycle icon-recommended Production

At least one model within this product family is in production and available for purchase. The product is appropriate for new designs but newer alternatives may exist.
