Features
- Four ADCs in one package
- Small footprint: 7 mm x 7 mm chip scale package
- Serial LVDS digital output data rates up to
- 780 Mbps (ANSI-644)
- Data and Frame clock output provided
- SNR = 69.5 dB (to Nyquist)
- 400 MHz full power analog bandwidth
- Power dissipation = 246 mW per ADC at
50 MSPS - Excellent Linearity:
- DNL = ±0.3 LSB (typical)
- INL = ±0.4 LSB (typical) - 1 V pp – 2 V pp input voltage range
- +3.0 V supply operation
- Power down mode
.svg?rev=fd385c90e2cf4716ae9a8c8d20e6b8e3&la=en&h=24&w=24&hash=A302DF48F94BAAA11877AF223F27157A){kind=icon}
The AD9229 is a 50 or 65 MSPS quad 12-bit, analog–to–digital converter with serial LVDS outputs. An on–chip track–and–hold circuit is designed for low cost, low power, small size and ease of use. The product operates up to a 65 MSPS conversion rate and is optimized for outstanding dynamic performance where a small package size is critical.
The ADC requires a single +3 V power supply. No external reference or driver components are required for many applications. A separate output power supply pin supports LVDS compatible serial digital output levels.
The ADC automatically multiplies up the sample rate clock for the appropriate LVDS serial data rate. This data clock output (DCO) provides operation up to 390 MHz and supports double-data rate operation (DDR). An MSB trigger or Frame clock is also provided to signal a new output byte. Power down is supported, and the ADC consumes 3 mW when enabled.
Fabricated on an advanced CMOS process, the AD9229 is available in a 48-pin chip scale 7 mm x 7 mm package (48-LFCSP) specified over the industrial temperature range (–40°C to +85°C).
Applications
Ask a Question
Submit your question below and we will return the best answer from ADI’s knowledge database:
Search
Other places you can find help
Support
Analog Devices Support Portal is a one-stop shop to answer all your ADI questions.
Visit the ADI Support Page
{{modalTitle}}
{{modalDescription}}
{{dropdownTitle}}
- {{defaultSelectedText}} {{#each projectNames}}
- {{name}} {{/each}} {{#if newProjectText}}
-
{{newProjectText}}
{{/if}}
{{newProjectTitle}}
{{projectNameErrorText}}
AD9229
Documentation
Filters
1 Applied
-
All
-
Application Note
-
Data Sheet
-
Technical Articles
-
All
-
English
-
Chinese
-
Japanese
Data Sheet
2
Application Note
37
359 kB
1076 kB
823 kB
491 kB
1559 kB
1606 kB
HTML
HTML
HTML
HTML
HTML
HTML
HTML
HTML
HTML
Technical Articles
3
URL
URL
URL
Documentation
Data Sheet 1
Application Note 13
AN-715: A First Approach to IBIS Models: What They Are and How They Are Generated (Rev.0)
AN-827: A Resonant Approach to Interfacing Amplifiers to Switched-Capacitor ADCs (Rev.0)
AN-756: Sampled Systems and the Effects of Clock Phase Noise and Jitter (Rev.0)
AN-808: Multicarrier CDMA2000 Feasibility (Rev.0)
AN-737: How ADIsimADC Models an ADC (Rev.B)
AN-586: LVDS Outputs for High Speed A/D Converters (Rev.0)
AN-741: Little Known Characteristics of Phase Noise (Rev.0)
AN-501: Aperture Uncertainty and ADC System Performance (Rev.A)
AN-345: Grounding for Low-and-High-Frequency Circuits
AN-282: Fundamentals of Sampled Data Systems
AN-835: Understanding High Speed ADC Testing and Evaluation
AN-1142: Techniques for High Speed ADC PCB Layout
AN-905: VisualAnalog™ Converter Evaluation Tool Version 1.0 User Manual
Technical Articles 3
Analog Dialogue 1
ADI has always placed the highest emphasis on delivering products that meet the maximum levels of quality and reliability. We achieve this by incorporating quality and reliability checks in every scope of product and process design, and in the manufacturing process as well. "Zero defects" for shipped products is always our goal. View our quality and reliability program and certifications for more information.
| Part Model | Pin/Package Drawing | Documentation | CAD Symbols, Footprints, and 3D Models |
|---|---|---|---|
| AD9229ABCPZ-50 |
48-Lead LFCSP (7mm x 7mm x 0.85mm w/ EP)
|
|
|
| AD9229ABCPZ-65 |
48-Lead LFCSP (7mm x 7mm x 0.85mm w/ EP)
|
|
|
| AD9229ABCPZRL7-50 |
48-Lead LFCSP (7mm x 7mm x 0.85mm w/ EP)
|
|
|
| AD9229ABCPZRL7-65 |
48-Lead LFCSP (7mm x 7mm x 0.85mm w/ EP)
|
|
- AD9229ABCPZ-50
- Pin/Package Drawing
-
48-Lead LFCSP (7mm x 7mm x 0.85mm w/ EP)
- Documentation
-
HTML
Material Declaration
-
HTML
Reliablity Data
- CAD Symbols, Footprints, and 3D Models
-
Ultra Librarian
-
SamacSys
- AD9229ABCPZ-65
- Pin/Package Drawing
-
48-Lead LFCSP (7mm x 7mm x 0.85mm w/ EP)
- Documentation
-
HTML
Material Declaration
-
HTML
Reliablity Data
- CAD Symbols, Footprints, and 3D Models
-
Ultra Librarian
-
SamacSys
- AD9229ABCPZRL7-50
- Pin/Package Drawing
-
48-Lead LFCSP (7mm x 7mm x 0.85mm w/ EP)
- Documentation
-
HTML
Material Declaration
-
HTML
Reliablity Data
- CAD Symbols, Footprints, and 3D Models
-
Ultra Librarian
-
SamacSys
- AD9229ABCPZRL7-65
- Pin/Package Drawing
-
48-Lead LFCSP (7mm x 7mm x 0.85mm w/ EP)
- Documentation
-
HTML
Material Declaration
-
HTML
Reliablity Data
- CAD Symbols, Footprints, and 3D Models
-
Ultra Librarian
-
SamacSys
Filter by Model
Part Models
Product Lifecycle
PCN
Jun 9, 2021
- 20_0126
Conversion of Select Sizes LFCSP Products from Punched to Sawn and Transfer of Assembly Site to ASE Korea
AD9229ABCPZ-50
PRODUCTION
AD9229ABCPZ-65
PRODUCTION
Sep 13, 2017
- 16_0077
CANCELLED: Conversion of Select 4x4, 5x5, 6x6 and 7x7mm LFCSP Package Outlines from Punch to Sawn and Transfer of Assembly Site to ASE Korea.
AD9229ABCPZ-50
PRODUCTION
AD9229ABCPZ-65
PRODUCTION
Jan 29, 2014
- 14_0014
ADI Corporate Obsolescence Notice-January 2014 (Standard Products)
AD9229ABCPZRL7-50
Obsolete
AD9229ABCPZRL7-65
Obsolete
Filter by Model
Part Models
Product Lifecycle
PCN
Jun 9, 2021
- 20_0126
Conversion of Select Sizes LFCSP Products from Punched to Sawn and Transfer of Assembly Site to ASE Korea
AD9229ABCPZ-50
PRODUCTION
AD9229ABCPZ-65
PRODUCTION
Sep 13, 2017
- 16_0077
CANCELLED: Conversion of Select 4x4, 5x5, 6x6 and 7x7mm LFCSP Package Outlines from Punch to Sawn and Transfer of Assembly Site to ASE Korea.
AD9229ABCPZ-50
PRODUCTION
AD9229ABCPZ-65
PRODUCTION
Jan 29, 2014
- 14_0014
ADI Corporate Obsolescence Notice-January 2014 (Standard Products)
