![48-Lead Low Profile Quad Flat Package [LQFP]](https://www.analog.com/-/media/analog/en/products/image/pin-diagrams/ad7678-pc.png?la=en&imgver=2&h=500)
![48-Lead Lead Frame Chip Scale Package [LFCSP]](https://www.analog.com/-/media/analog/en/products/image/pin-diagrams/ad7678-pc1.png?la=en&imgver=1&h=500)
![48-Lead Low Profile Quad Flat Package [LQFP]](https://www.analog.com/-/media/analog/en/products/image/pin-diagrams/ad7678-pc.png?la=en&imgver=2&h=270)
![48-Lead Lead Frame Chip Scale Package [LFCSP]](https://www.analog.com/-/media/analog/en/products/image/pin-diagrams/ad7678-pc1.png?la=en&imgver=1&h=270)
-
AD7678: 18-Bit, 2.5 LSB INL, 100 kSPS SAR ADC Data Sheet (Rev. B)8/1/2003PDF1160 kB
Alternative Parts
Overview
Features and Benefits
- 18-bit resolution with no missing codes
- No pipeline delay (SAR architecture)
- Differential input range: ±VREF (VREF up to 5 V)
- Throughput: 100 kSPS
- INL: ±2.5 LSB max (±9.5 ppm of full scale)
- Dynamic range: 103 dB typ (VREF = 5 V)
- S/(N+D): 100 dB typ @ 2 kHz (VREF = 5 V)
- Parallel (18-,16-, or 8-bit bus) and serial 5 V/3 V interface
- SPI®/QSPI™/MICROWIRE™/DSP compatible
- On-board reference buffer
- Single 5 V supply operation
- Power dissipation: 18 mW @ 100 kSPS, 180 μW @ 1 kSPS
- 48-lead LQFP or 48-lead LFCSP package
- Pin-to-pin compatible upgrade of AD7674/AD7676/AD7679
Product Details
The AD7678 is an 18-bit, 100 kSPS, charge redistribution SAR, fully differential analog-to-digital converter that operates on a single 5 V power supply. The part contains a high speed 18-bit sampling ADC, an internal conversion clock, an internal reference buffer, error correction circuits, and both serial and parallel system interface ports.The part is available in 48-lead LQFP or 48-lead LFCSP packages with operation specified from –40°C to +85°C.
Product Categories
Product Lifecycle
Production
At least one model within this product family is in production and available for purchase. The product is appropriate for new designs but newer alternatives may exist.
