AD532

NOT RECOMMENDED FOR NEW DESIGNS

Internally Trimmed Integrated Circuit Multiplier

Data Sheet (Rev. F) Product Selection Table

Part Models: 10
1ku List Price: Starting From $48.88

Viewing:

Overview

Pretrimmed to ±1.0% (AD532K)
No external components required
Guaranteed ±1.0% maximum 4-quadrant error (AD532K)

Differential inputs for (X₁ - X₂) (Y₁ - Y₂)/10 V transfer function
Monolithic construction, low cost

The AD532 is the first pretrimmed single chip monolithic multiplier/divider. It guarantees a maximum multiplying error of ±1.0% and a ±10 V output voltage without the need for any external trimming resistors or output op amp. Because the AD532 is internally trimmed, its simplicity of use provides design engineers with an attractive alternative to modular multipliers, and its monolithic construction provides significant advantages in size, reliability and economy. Further, the AD532 can be used as a direct replacement for other IC multipliers that require external trim networks (such as the AD530).

APPLICATIONS

Multiplication, division, squaring, square rooting
Algebraic computation
Power measurements
Instrumentation applications
Available in chip form
