AD5260
+15 V or ±5 V, Single-Channel, SPI Compatible, 256 Position Digital Potentiometer
Show More
Not the part you were looking for?
Ask a Question
Submit your question below and we will return the best answer from ADI’s knowledge database:
Search
Other places you can find help
Support
Analog Devices Support Portal is a one-stop shop to answer all your ADI questions.
Visit the ADI Support Page
Features
- AD5262 – 2-Channel (Independently Programmable)
- Potentiometer Replacement 20 kO, 50 kO, 200 kO
- 5 V to 15 V Single-Supply; ±5.5 V Dual-Supply Operation
- 256 Positions
- AD5260 – 1-Channel
- Low Temperature Coefficient 35 ppm/°C
- 4-Wire SPI-Compatible Serial Data Input
- Power ON Mid-Scale Preset
.svg?rev=fd385c90e2cf4716ae9a8c8d20e6b8e3&la=en&h=24&w=24&hash=A302DF48F94BAAA11877AF223F27157A){kind=icon}
The AD5260 and AD5262 are 1- and 2-channel, 256 position, SPI interface digitally controlled, variable resistor (VR) devices. These parts operate from either a single +5 V to +15 V supply or a dual ±5 V supply, extending terminal voltage adjustment to these supply voltages. (Most industry digital potentiometers are limited to a 5 V operating range). These devices perform the same electronic adjustment function as a potentiometer or variable resistor while offering solid-state reliability and electronic packaging compactness. These devices are offered in the thin 1.1 mm height TSSOP 14- and 16-lead surface mount packages.
