HMC974

RECOMMENDED FOR NEW DESIGNS

10 GHz, High Speed Window Comparator

Data Sheet (Rev. E) Product Selection Table

Part Models: 3
1ku List Price: price unavailable

Viewing:

Part Details

Propagation delay: 88 ps
Propagation delay at 50 mV overdrive: 20 ps
Minimum detectable pulse width: 60 ps
Differential latch control
Power dissipation: 240 mW
16-terminal 2.9 mm × 2.9 mm LCC package

Part Models: 3
1ku List Price: price unavailable

Documentation

Data Sheet 1

HMC974LC3C: High Speed, 10 GHz Window Comparator Data Sheet (Rev.E) 03/23/2017

ADI has always placed the highest emphasis on delivering products that meet the maximum levels of quality and reliability. We achieve this by incorporating quality and reliability checks in every scope of product and process design, and in the manufacturing process as well. "Zero defects" for shipped products is always our goal. View our quality and reliability program and certifications for more information.

Part Model	Pin/Package Drawing	Documentation	CAD Symbols, Footprints, and 3D Models
HMC974LC3C	16-Lead LCC (3mm x 3mm w/ EP)	Material Declaration Reliablity Data	Ultra Librarian SamacSys
HMC974LC3CTR	16-Lead LCC (3mm x 3mm w/ EP)	Material Declaration Reliablity Data	Ultra Librarian SamacSys
HMC974LC3CTR-R5	16-Lead LCC (3mm x 3mm w/ EP)	Material Declaration Reliablity Data	Ultra Librarian SamacSys

Part Models	Product Lifecycle	PCN

Jun 16, 2017 - 17_0093 HMC974 Data Sheet Changes
		PCN17_0093_Form Material_Report
HMC974LC3C	PRODUCTION
HMC974LC3CTR	PRODUCTION
HMC974LC3CTR-R5	PRODUCTION
Aug 18, 2016 - 16_0084 HMC974 Die Revision and Data Sheet Change
		PCN16_0084_Form Material_Report
HMC974LC3C	PRODUCTION
HMC974LC3CTR	PRODUCTION
HMC974LC3CTR-R5	PRODUCTION
