HMC935

Obsolete

180° Analog Phase Shifter SMT, 2 - 20 GHz

Viewing:

Overview

Decade Bandwidth: 2 - 20 GHz
>180° Phase Shift
Low Insertion Loss: 4 dB

Single Positive Voltage Control
32 Lead 5 x 5mm QFN Package: 25 mm²

The HMC935LP5E is an Analog Phase Shifter which is controlled via an analog control voltage from 0.5 to +11V. The HMC935LP5E provides a continuously variable phase shift of 0 to 180 degrees from 2 to 20 GHz, with extremely consistent low insertion loss versus phase shift and frequency. The high accuracy HMC935LP5E is monotonic with respect to control voltage and features a typical low phase error of +20/-8 degrees. The HMC935LP5E is housed in an RoHS compliant 5 x 5 mm QFN leadless package.
