ADRF5345

RECOMMENDED FOR NEW DESIGNS

High Linearity, Silicon SP4T Switch, 30 MHz to 6 GHz

Data Sheet (Rev. A) Product Selection Table
Viewing:

Overview

  • Frequency range : 30 MHz to 6 GHz
  • Reflective design
  • Low Insertion Loss
    • 0.30 dB to 1.0 GHz typical
    • 0.35 dB to 2.8 GHz typical
    • 0.40 dB to 3.8 GHz typical
    • 0.45 dB to 5.0 GHz typical
    • 0.60 dB to 6.0 GHz typical
  • High power handling at TCASE = 105°C
    • Long-term (>10 years) average
      • Continuous wave power: 39 dBm
      • LTE signal
        • Average power: 39 dBm
        • Peak power: 49 dBm
  • High input linearity, IP3: 84 dBm typical
  • ESD ratings
    • HBM: 2000 V, Class 2
    • CDM: 1000 V, Class C3
  • Single-supply operation, integrated NVG
  • Positive control, LVCMOS-/LVTTL- compatible
  • 4 mm x 4 mm, 22-terminal LGA package

The ADRF5345 is a high linearity, reflective, single-pole, four-throw (SP4T) switch manufactured in the silicon process.

The ADRF5345 operates from 30 MHz to 6 GHz with a typical insertion loss lower than 0.40 dB up to 3.8 GHz, and a typical input IP3 of 84 dBm. The device has an RF input power handling capability of 39 dBm for continuous wave signals and 39 dBm average and 49 dBm peak for long-term evolution (LTE) signals.

The ADRF5345 incorporates an integrated negative voltage generator (NVG) to operate with a single positive supply of 5 V (VDD) applied to the VDD pin drawing a 2 mA supply current. The device employs low voltage complementary metal-oxide semiconductor (LVCMOS)-/low voltage transistor to transistor logic (LVTTL)- compatible controls.

The ADRF5345 comes in a 4 mm × 4 mm, 22-terminal, RoHS-compliant, land grid array (LGA) package and operates between −40°C to +105°C.

APPLICATIONS

  • 5G antenna tilting
  • Wireless infrastructure
  • Military and high reliability applications
  • Test equipment
  • Pin diode replacement

    •
    ADRF5345
    High Linearity, Silicon SP4T Switch, 30 MHz to 6 GHz
    ADRF5345 - Functional Block Diagram ADRF5345 - Pin Configuration
    Add to myAnalog

    Add product to the Products section of myAnalog (to receive notifications), to an existing project or to a new project.

    Create New Project
    Ask a Question

    Documentation

    Data Sheet 1

    User Guide 1

    Learn More
    Add to myAnalog

    Add media to the Resources section of myAnalog, to an existing project or to a new project.

    Create New Project

    Software Resources

    Can't find the software or driver you need?

    Request a Driver/Software

    Tools & Simulations

    S-Parameter 1

    Evaluation Kits

    eval board
    schematic 1
    schematic 2
    schematic 3
    EVAL-ADRF5345

    Evaluation of the ADRF5345 High Linearity, Silicon SP4T Switch, 30 MHz to 6 GHz

    Buy Now View Details

    Features and Benefits

  • Full featured evaluation board for the ADRF5345
  • Easy connection to test equipment
  • Thru line for calibration

    • Product Details

    The ADRF5345 is a high linearity, single-pole, four-throw (SP4T) switch manufactured in the silicon process.

    This user guide describes the ADRF5345-EVALZ evaluation board, designed to simply evaluate the features and performance of the ADRF5345. A photograph of the evaluation board is shown in Figure 1.

    The ADRF5345 data sheet provides full specifications for the ADRF5345. Consult the ADRF5345 data sheet in conjunction with this user guide when using the ADRF5345-EVALZ.
    EVAL-ADRF5345
    Evaluation of the ADRF5345 High Linearity, Silicon SP4T Switch, 30 MHz to 6 GHz
    ADRF5345-EVALZ Evaluation Board ADRF5345-EVALZ Evaluation Board - Top View ADRF5345-EVALZ Evaluation Board - Bottom View
