MAXQ611

Infrared Remote Control System-On-Chip

Viewing:

产品详情

Fast, Compact Architecture Allows Easy Integration into Applications
- Internal 12MHz Oscillator Requires No External Components
- Efficient, 16-Bit MAXQ20S RISC Core
- 1.7V to 3.6V Wide Operating Range
- 80KB Flash Program Memory
- 2KB SRAM for Data Storage
- Default V_PFW Compatible with MAXQ610
Integrated IR Module Reduces Cost and Development Time
- Transmit and Receive (Code Learning) Modes
- Automatic Carrier Generation/Modulation
- Glitch Filter Improves Noise Immunity
- Configurable High-Current Driver
Peripherals Support Multiple Applications
- Up to 32 (TQFN) or 38 (Bare Die) GPIO
- Two 16-Bit Programmable Timers/Counters Include Capture/Compare Functionality
- SPI, I²C, and Two USART Busses
- Programmable Watchdog Timer Enhances System Stability
Low Power Consumption Maximizes Battery Life
- Power-Fail Warning Circuit Minimizes Effects of Power Fluctuation
- Power-On and Brownout Reset Circuitry
- 2.0mA (typ) at 12MHz in Active Mode
