概览

优势和特点

Features

  • 100% Bitstream Compatible with the ADV601
  • Precise Compressed Bit Rate Control
  • Field Independent Compression
  • 8-Bit Video Interface Supports CCIR-656 and Multiplexed Philips Formats
  • General Purpose 16- or 32-Bit Host Interface with 512 Deep 32-Bit FIFO

Performance

  • Real-Time Compression or Decompression of CCIR-601 to Video:
    720 x 288 @ 50 Fields/Sec - PAL
    720 x 288 @ 60 Fields/Sec - NTSC
  • Compression Ratios from Visually Loss-Less to 350:1
  • Visually Loss-Less Compression At 4:1 on Natural Images (Typical)

产品详情

ADV601和ADV601LC均为极低成本、单芯片、专用功能、全数字CMOS VLSI器件,能够对CCIR-601数字视频进行高达350:1的视觉无损实时压缩和解压缩,图像质量很高。ADV601可提供每分量10位的处理性能和专用DSP串行端口,采用160引脚PQFP封装。ADV601LC提供每分量8位的处理性能,无DSP串行端口,成本超低,采用120引脚小型TQFP封装。

产品分类

产品生命周期 icon-not-recommended 新设计不推荐使用本产品

表示相关产品已过时,ADI公司不再推荐新设计使用。
