How do you measure and computed the slew rate in the unity-gain buffer configuration? Compare this with the value listed in the OP97 data sheet.
Summing circuit: using superposition, derive the expected transfer characteristic for the circuit of - find the output voltage in terms of Vin0, Vin1, Vin2 and Vin3. Compare the predictions of the ideal relationship with your data.
Comparator: What would happen if the polarity of Vref is reversed?
