MAX136: 低電力、3 1/2桁A/Dコンバータ、ディスプレイホールド内蔵 Data Sheet (Rev. 1)1/1/1900PDF794K
製品概要
機能と利点
- Power Dissipation Guaranteed Less than 1mW–9V Battery Life 3000 Hours Typical
- Hold Pin Allows Indefinite Display Hold
- Guaranteed First Reading Recovery from Overrange
- On-Board Display Drive Capability—No External Circuitry Required
- High-Impedance CMOS Differential Inputs
- Low Noise (< 15µVP-P) Without Hysteresis or Overrange Hangover
- Clock and Reference On-Chip
- Zero Input Gives Zero Reading
- True Polarity Indication for Precision Null Applications
- Key Parameters Guaranteed Over Temperature
製品概要
アプリケーション
- コンダクタンス
- 電流
- 材料厚
- 圧力
- 抵抗
- 速度
- 温度
- 電圧
