Overview

Features and Benefits

  • TMC5271 Stepper Motor Driver & Controller
  • Supply Voltage 2.1V to 20V DC
  • Iphase up to 1.6ARMS
  • StealthChop2 Silent PWM Mode
  • StallGuard4 Sensorless Motor Load Detection
  • TriCoder Sensorless Standstill Steploss Detection and Full Step Encoder
  • Board Width 1.0", Board Height 1.0"
  • 2 x 10 Pin 0.1" Header Rows for Connectors
