Overview
Features and Benefits
- 1% max Initial Accuracy
- 100ppm/°C max Temperature Coefficient
- 45µA max Quiescent Supply Current
- 0.8µA/V Supply Current Variation with VIN
- ±400µA Output Source and Sink Current
- 100mV Dropout at 400µA Load Current
- 0.12µV/µA Load Regulation
- 8µV/V Line Regulation
- Stable with CLOAD = 0 to 2.2nF
Product Details
The MAX6001-MAX6005 family of SOT23, low-cost series voltage references meets the cost advantage of shunt references and offers the power-saving advantage of series references, which traditionally cost more. Unlike conventional shunt-mode (two-terminal) references that must be biased at the load current and require an external resistor, these devices eliminate the need for an external resistor and offer a supply current that is virtually independent of the supply voltage.
These micropower, low-dropout, low-cost devices are ideal for high-volume, cost-sensitive 3V and 5V battery- operated systems with wide variations in supply voltage that require very low power dissipation. Additionally, these devices are internally compensated and do not require an external compensation capacitor, saving valuable board area in space-critical applications.
Applications
- Cell Phones
- Hard Disk Drive
- Notebook Computers
- Pagers
- PDAs, GPSs, DMMs
- Portable Battery-Powered Equipment
Product Categories
Product Lifecycle
Production
At least one model within this product family is in production and available for purchase. The product is appropriate for new designs but newer alternatives may exist.
