MAX34417
SMBus Four-Channel Very Wide Dynamic Range Power Accumulator
Achieve Longer Battery Life in Mobile Devices
Top
Overview
Features and Benefits
- Enables Code Optimization to Minimize Power Consumption in Portable Platforms
- Four Power Monitors with Wide 86dB Dynamic Range
- Measures Both Current and Voltage
- Low Power Consumption
- Reduced Power Consumption in Slow Accumulation Mode
- Power-Down Mode
- Minimizes Processor Overhead with Autonomous Operation
- Per Channel 56-Bit Power Accumulators Capture 4.55 Hours of Data at 1024 Samples per Second
- Per Channel 14-Bit Voltage Registers
- High-Integration Solution Minimizes Parts Count, PCB Space, and BOM Cost
- Wide Current Common-Mode Range of 0.5V to 20V
- Low Full-Scale, Current-Sense Voltage of 100mV
- As low as 5μV Current-Sense Voltage
- I2C/SMBus Interface with Bus Timeout
- Temperature Range: -40°C to +85°C
- Small, 2mm x 2mm Footprint Wafer-Level Package (WLP) with 16 Bumps at 0.4mm Pitch
- Ease of Development
- Evaluation Kit with Advanced GUI Available
Product Details
The MAX34417 is a specialized current and voltage monitor used to determine power consumption of portable systems. The device has a very wide dynamic range (20,000:1) that allows for the accurate measurement of power in such systems. The device is configured and monitored with a standard I2C/SMBus serial interface. The unidirectional current sensor offers precision high-side operation with a low full-scale sense voltage. The device automatically collects the current-sense and voltage samples and then multiplies those values to obtain a power value it then accumulates. Upon a command from the host, the device transfers the accumulated power samples, as well as the accumulation count, to a set of registers accessible by the host. This transfer occurs without missing a sample and allows the host to retrieve the data not in real-time, but at any time interval.
Watch video: Introducing the MAX34417 Evaluation Kit
Applications
- Servers
- Smartphones
- Tablets
- Ultra Notebooks
Product Categories
Product Lifecycle
Production
At least one model within this product family is in production and available for purchase. The product is appropriate for new designs but newer alternatives may exist.
