MAX33053E

PRODUCTION

+3.3V, 2Mbps CAN Transceiver with ±65V Fault Protection, ±25V CMR, and ±25kV ESD

2Mbps CAN Transceiver with High Protection and Multi-Function STBY Pin in 8-Pin SO

Data Sheet (Rev. 1) Product Selection Table
Viewing:

Overview

  • Integrated Protection Increases Robustness
    • ±65V Fault Tolerant CANH and CANL
    • ±25kV ESD HBM (Human Body Model)
    • ±25V Extended Common Mode Input Range (CMR)
    • Transmitter Dominant Timeout Prevents Lockup
    • Short-Circuit Protection
    • Thermal Shutdown
  • Family Provides Flexible Design Options
    • Slow Slew Rate to minimize EMI
    • Silent Mode S Disables Transmitter
    • STBY Input for Low-Current Mode, Slow Slew Rate
    • 1.62V to 3.6V Logic-Supply (VL) Range
  • High-Speed Operation of Up to 2Mbps
  • Operating Temperature Range of -40°C to +125°C in 8-pin SOIC Package

The MAX33053E and MAX33054E are +3.3V CAN (Control Area Network) transceivers with integrated protection for industrial applications. These devices have extended ±65V fault protection for equipment where overvoltage protection is required. It also incorporates high ±25kV ESD HBM and an input common mode range (CMR) of ±25V, exceeding the ISO11898 specification of -2V to +7V. This makes these parts well-suited for applications that are in electrically noisy environments where the ground planes are shifting relative to each other. This family features a variety of options to address common CAN application requirements; logic-level supply input VL for interfacing with 1.62V to 3.6V logic, low-current standby mode, silent-mode to disable the transmitter, and a slow slew rate to minimize EMI.

These devices operate at a high-speed CAN data rate, allowing up to 2Mbps on small networks. Maximum speed on large networks may be limited by the number of nodes in a network, the type of cabling used, stub length, and other factors. These transceivers include a dominant timeout to prevent bus lockup caused by controller error or by a fault on the TXD input. When TXD remains in the dominant state (low) for longer than TDOM, the driver is switched to the recessive state, releasing the bus. The MAX33053E features an S pin where it enables and disables the transmitter for applications where you need the transceiver to receive only. The MAX33054E features a STBY pin for 3 modes of operation; standby mode for low-current consumption, normal high-speed mode, or a slow slew rate mode when an external 26.1kΩ is connected between ground and STBY pin.

The MAX33053E and MAX33054E are available in a standard 8-pin SOIC package and operate over the -40°C to +125°C temperature range.

Mobile App

Applications

  • Building Automation
  • Drone
  • Industrial Automation
  • Instrumentation
  • Motor Control
  • Programmable Logic Controller
  • Smart Grid Equipment
MAX33053E
+3.3V, 2Mbps CAN Transceiver with ±65V Fault Protection, ±25V CMR, and ±25kV ESD
MAX33053E, MAX33054E: Simplified Block Diagram
Add to myAnalog

Add product to the Products section of myAnalog (to receive notifications), to an existing project or to a new project.

Create New Project
Ask a Question

Documentation

Data Sheet 1

Learn More
Add to myAnalog

Add media to the Resources section of myAnalog, to an existing project or to a new project.

Create New Project

Evaluation Kits

MAX33054ESHLD

Evaluation Kit for the MAX33054E

Buy Now View Details

Features and Benefits

  • Integrated Protection Increases Robustness
    • ±65V Fault Tolerant CANH and CANL
    • ±25kV ESD HBM (Human Body Model)
    • ±25V Extended Common Mode Input Range (CMR)
    • Transmitter Dominant Timeout Prevents CAN Bus Lockup
    • Short-Circuit Protection
    • Thermal Shutdown
  • MAX33054E Provides Flexible Design Options
    • STBY Input for Low-Current Mode, Slow Slew Rate, Normal Operating Mode
    • 1.62V to 3.6V Logic-Supply (VL) Range
  • High-Speed Operation of Up to 2Mbps
  • Operating Temperature Range of -40ºC to +125ºC in 8-pin SOIC Package

Product Details

The MAX33054E Shield is a fully assembled and tested PCB that demonstrates the functionality of the MAX33054E fault-protected with extended common mode input range and ±25kV ESD Human Body Model (HBM) controller area network (CAN) transceiver. The shield features a digital isolator, used as a level translator (between the controller and transceiver) and operates from 1.71V to 5.5V supply.

MAX33053ESHLD

Evaluation Kit for the MAX33053E

Buy Now View Details

Features and Benefits

  • Integrated Protection Increases Robustness
    • ±65V Fault Tolerant CANH and CANL
    • ±25kV ESD HBM (Human Body Model)
    • ±25V Extended Common Mode Input Range (CMR)
    • Transmitter Dominant Timeout Prevents CAN Bus Lockup
    • Short-Circuit Protection
    • Thermal Shutdown
  • MAX33053E Provides Flexible Design Options
    • Silent Mode S Enables/Disables Transmitter
    • 1.62V to 3.6V Logic-Supply (VL) Range
  • High-Speed Operation of Up to 2Mbps
  • Operating Temperature Range of -40ºC to +125ºC in 8-pin SOIC Package

Product Details

The MAX33053E Shield is a fully assembled and tested PCB that demonstrates the functionality of the MAX33053E fault-protected with extended common mode input range and ±25kV ESD Human Body Model (HBM) controller area network (CAN) transceiver. The shield features a digital isolator, used as a level translator (between the controller and the transceiver) and operates from a range of 1.71V to 5.5V supply.

Applications

  • Building Automation
  • Drone
  • Industrial Automation
  • Instrumentation
  • Motor Control
  • Programmable Logic Controller
  • Smart Grid Equipment
MAX33054ESHLD
Evaluation Kit for the MAX33054E
MAX33053ESHLD
Evaluation Kit for the MAX33053E
