MAX33045E
20Mbps, Half-Duplex RS-485/RS-422 Transceivers with ±40kV ESD Protection
Highest ESD RS-485 with Dual Voltage, 1/8 Load and ±25V Fault Protection
Top
Overview
Features and Benefits
- Integrated Protection Increases Robustness
- ±25V Fault-Protection Range on Driver Outputs/Receiver Inputs
- High-ESD Protection
- ±40kV HBM ESD per JEDEC JS-001
- ±15kV Air-Gap ESD per IEC 61000-4-2
- ±10kV Contact ESD per IEC 61000-4-2
- Short-Circuit-Protected Outputs
- True Fail-Safe Receiver Prevents False Transition on Receiver Input Short or Open Events
- Hot-Swap Capability Eliminates False Transitions on Receiver Input Shorts or Open Events
- High-Speed Data Rates up to 20Mbps
- Enables up to 256 Nodes on the Bus
- Wide -40°C to +125°C Operating Temperature Range
Product Details
The MAX33045E/MAX33046E is a half-duplex RS-485/422 transceiver that operates at either 3.3V or 5.0V supply rail for ease of design. Both devices feature enhanced protection for applications in harsh environments. All driver outputs and receiver inputs are protected with both high-fault and high-ESD (electrostatic discharge) protection.
The A/B lines have up to ±25V fault protection for accidental shorts with local power supplies and ±40kV ESD (Human Body Model) HBM protection. They are also rated up to ±15kV Air-Gap Discharge and ±10kV Contact Discharge per IEC 61000-4-2. Both features ensure robust protection in harsh industrial environments. Drivers are short-circuit current limited and protected against excessive power dissipation by thermal-shutdown circuitry that places the driver outputs into a high-impedance state. The receiver input has a true fail-safe feature that guarantees a logic-high output if both inputs are open or short circuited.
The MAX33045E is rated for a 500kbps (min) data rate, and the MAX33046E is rated for a 20Mbps data rate.
Both devices are packaged in an 8-pin SOIC with an operating ambient temperature from -40°C to +125°C.
Applications
- Backplane Buses
- Encoder Interfaces
- Factory Automation Equipment
- Motion Controllers
- Programmable Controller
- Telecommunication Equipment
Product Categories
Product Lifecycle
Production
At least one model within this product family is in production and available for purchase. The product is appropriate for new designs but newer alternatives may exist.
