MAX31341C

Low-Current, Real-Time Clock with I2C Interface and Power Management

Show More showmore-icon

Industry's Smallest RTC with Very Low Time Keeping Current

Info: : PRODUCTION tooltip
Info: : PRODUCTION tooltip
Part Details
Part Models 2
1ku List Price Starting From $0.86
Features
  • Increases Battery Life
    • 180nA Timekeeping Current
    • Wide Range of External Crystals with CL = 6pF and ESR up to 100kΩ for Minimal Current Draw
    • Trickle Charger for External Super Capacitor or Rechargeable Battery
  • Provides Flexible Configurability
    • A Schmitt Trigger Input to Trigger Interrupt
    • One Analog Input with Adjustable Threshold to Trigger Interrupt
    • Programmable Square Wave Output for Clock Monitoring
  • Saves Board Space
    • Integrated Load Capacitors for Crystal Oscillator
    • 2mm x 1.5mm, 12-Bump WLP with 0.5mm Pitch
    • 3mm x 3mm, 10-pin TDFN
  • Value Add Features for Ease-of-Use
    • +1.6V to +3.6V Operating Voltage Range
    • Countdown Timer with Repeat and Pause Functions
    • 64-Byte RAM for User Data Storage
  • Integrated Protection
    • Power-On Reset for Default Configuration
    • Automatic Switchover to Backup Battery or Super Capacitor On Power Fail
    • Lockup-Free Operation with Bus Timeout
Additional Details
show more Icon

The MAX31341B/MAX31341C low-current, real-time clock (RTC) is a time-keeping device that provides nanoamperes timekeeping current, extending battery life. The MAX31341B/MAX31341C supports 6pF high-ESR crystals, which broaden the pool of usable crystals for the devices. This device is accessed through an I2C serial interface. The device features one digital Schmitt trigger input and one programmable threshold analog input. The device generates an interrupt output on a falling or rising edge of the digital input (D1), or when the analog input (AIN) voltage crosses a programmed threshold in either direction. An integrated power-on reset function ensures deterministic default register status upon power-up.

Other features include two time-of-day alarms, interrupt outputs, a programmable square-wave output, a serial bus timeout mechanism, and a 64-byte RAM for user data storage. The clock/calendar provides seconds, minutes, hours, day, date, month, and year information. The date at the end of the month is automatically adjusted for months with fewer than 31 days, including corrections for leap year. The clock operates in 24-hour format. The MAX31341B/MAX31341C also includes an input for synchronization. When a reference clock (e.g., 32kHz, 50Hz/60Hz Power Line, GPS 1PPS) is present at the CLKIN pin and the enable external clock input bit (ECLK) is set to 1, the MAX31341B/MAX31341C RTC is frequency-locked to the external clock and the clock accuracy is determined by the external source.

The device is available in lead (Pb)-free/RoHS-compliant, 12-pin, 2mm x 1.5mm WLP with 0.5mm pitch and 10-pin, 3mm x 3mm TDFN. The device supports the -40°C to +85°C extended temperature range.

Design Solution: Give Your Wearable’s Micro Some Quality Sleep Time ›

Mobile App

Applications

  • Medical
  • Point-of-Sale (POS)
  • Portable Audio
  • Portable Instruments
  • Telematics
  • Wearables
Part Models 2
1ku List Price Starting From $0.86

close icon
Documentation

Documentation

Part Model Pin/Package Drawing Documentation CAD Symbols, Footprints, and 3D Models
MAX31341CETB+
  • HTML
  • HTML
MAX31341CETB+T
  • HTML
  • HTML
Software & Part Ecosystem

Software & Part Ecosystem

Evaluation Kit

Evaluation Kits 2

reference details image

MAX31341SHLD

Evaluation Kit for the MAX31341B/MAX31341C

zoom

MAX31341SHLD

Evaluation Kit for the MAX31341B/MAX31341C

Evaluation Kit for the MAX31341B/MAX31341C

Features and Benefits

  • Easy Evaluation of the MAX31341B and MAX31341C
  • +1.6V to 3.6V Single-Supply Operation
  • Proven PCB Layout
  • Fully Assembled and Tested

Product Detail

The MAX31341 Shield evaluation kit (EV kit) is a fully assembled and tested PCB to evaluate the MAX31341B and MAX31341C, low-cost, extremely accurate, real-time clocks (RTCs) with I2C interface and power manage- ment. The EV kit operates from a single supply, either from USB or an external power supply, and the onboard crystal provides a 32.768kHz clock signal. This device is accessed through an I2C serial interface provided by a MAX32625PICO board from a PC USB port.

The MAX31341 Shield EV kit provides the hardware and software user interface (GUI) necessary to evaluate the MAX31341B and MAX31341C. The EV kit includes a MAX31341B and a MAX31341C installed. It connects to the PC through a MAX32625 PICO board and a Micro USB cable.

Applications

  • Medical
  • Point-of-Sale (POS)
  • Portable Audio
  • Portable Instruments
  • Telematics
  • Wearables
reference details image

MAX31341EVKIT

Evaluation Kit for the MAX31341B/MAX31341C

zoom

MAX31341EVKIT

Evaluation Kit for the MAX31341B/MAX31341C

Evaluation Kit for the MAX31341B/MAX31341C

Features and Benefits

  • Easy Evaluation of the MAX31341B and MAX31341C
  • +1.6V to 3.6V Single-Supply Operation
  • Proven PCB Layout
  • Fully Assembled and Tested

Product Detail

The MAX31341 Shield evaluation kit (EV kit) is a fully assembled and tested PCB to evaluate the MAX31341B and MAX31341C, low-cost, extremely accurate, real-time clocks (RTCs) with I2C interface and power manage- ment. The EV kit operates from a single supply, either from USB or an external power supply, and the onboard crystal provides a 32.768kHz clock signal. This device is accessed through an I2C serial interface provided by a MAX32625PICO board from a PC USB port.

The MAX31341 Shield EV kit provides the hardware and software user interface (GUI) necessary to evaluate the MAX31341B and MAX31341C. The EV kit includes a MAX31341B and a MAX31341C installed. It connects to the PC through a MAX32625 PICO board and a Micro USB cable.

Applications

  • Medical
  • Point-of-Sale (POS)
  • Portable Audio
  • Portable Instruments
  • Telematics
  • Wearables
