MAX25611D
Automotive High-Voltage, HB-LED Controller
Compact and Flexible LED Driver Controller for Automotive LED Lighting Applications
Top
Overview
Features and Benefits
- Automotive Ready: AEC-Q100 Qualified
- Integration Minimizes BOM for High-Brightness LED Driver
- Integrated pMOS Dimming FET Gate Driver Allows Single-Wire Connection to LED String
- PWM, Analog-to-PWM and Analog Dimming
- Integrated High-Side, Current-Sense Amplifier
- 12-Pin SWTQFN-EP Package
- Flexible Application Configurations
- +5V to +36V Wide Input Voltage Range with a Maximum +65V Boost Output
- Boost, Buck-Boost, High-Side Buck, SEPIC, Zeta, and Cuk Single-Channel LED Drivers
- Protection Features and Wide Temperature Range Increase System Reliability
- Short-Circuit, Overvoltage, and Thermal Protection
- -40°C to +125°C Operating Temperature Range
Product Details
The MAX25611A/MAX25611B/MAX25611C/MAX25611D are single-channel HBLED drivers for automotive front light applications such as high beam, low beam, daytime running light (DRL), turn indicator, fog light, and other LED lights. It can take an input voltage from 5V to 36V and can drive a string of LEDs with a maximum output voltage of 65V.
The MAX25611A/B/C/D sense output current at the high side of the LED string. High-side current sensing is required to protect for shorts from the output to the ground or battery input. It is also the most flexible scheme for driving LEDs, allowing boost, high-side buck, SEPIC mode, or buck-boost mode configurations. The PWM input provides LED dimming ratios of up to 5000:1, and the REFI input provides additional analog dimming capability in the MAX25611A/B/C/D. The MAX25611A/B/C/D have built-in spread-spectrum modulation for improved electromagnetic compatibility performance. The MAX25611A/B/C/D can also be used in zeta and Cuk converter configurations if it is necessary in some applications.
The MAX25611A/B/C/D are available in a space-saving 12-pin SWTQFN-EP package. They are specified to operate over the -40°C to +125°C automotive temperature range. The switching frequency is internally set at 350kHzfor the MAX25611A/MAX25611C and 2.2MHz for theMAX25611B/MAX25611D.
Design Solution: Keep Your Head Up with a High-Dimming Ratio Automotive Led Driver ›
Applications
- Automotive Exterior Lighting
- Commercial, Industrial, and Architectural Lighting
- Daytime Running Lights (DRLs)
- Fog Lights and Adaptive Front Light Assemblies
- Head-Up Displays
- High Beam/Low Beam/Signal/Position lights
Product Categories
Product Lifecycle
Production
At least one model within this product family is in production and available for purchase. The product is appropriate for new designs but newer alternatives may exist.
