MAX25601C

PRODUCTION

Synchronous Boost and Synchronous Buck LED Controllers

Automotive Synchronous Boost Controller with Buck LED Controller Optimizes 2 Stage LED Lighting Designs

Part Models
2
1ku List Price
Starting From $3.38
Viewing:

Part Details

  • Integration Minimizes BOM for High-Brightness LED Driver, Saving Space and Cost
    • Wide Input-Voltage Range from 4.5V to 40V
    • Wide Boost-Output Range up to 65V
    • Programmable Switching Frequency Optimizes Component Size
    • External MOSFETs Can be Sized for Appropriate Current
    • Synchronous Rectification Provides High Efficiency and Fast Transient Response
    • Average Current-Mode Control for Buck Eliminates Compensation Components
  • Wide Dimming Ratio Allows High Contrast Ratio
    • Analog Dimming and PWM Dimming
    • Analog Voltage-Controlled PWM Dimming
  • Protection Features and Wide Temperature Range Increase System Reliability
    • Short Circuit, Overvoltage, and Thermal Protection
    • -40°C to +125°C Operating Temperature Range
MAX25601C
Synchronous Boost and Synchronous Buck LED Controllers
MAX25601A, MAX25601B, MAX25601C, MAX25601D: Simplified Application Circuit
Add to myAnalog

Add product to the Products section of myAnalog (to receive notifications), to an existing project or to a new project.

Create New Project
Ask a Question

Documentation

Learn More
Add to myAnalog

Add product to the Products section of myAnalog (to receive notifications), to an existing project or to a new project.

Create New Project

Hardware Ecosystem

Parts Product Life Cycle Description
LED Driver Support Functions 1
MAX20092 PRODUCTION 12-Switch Matrix Manager for Automotive Lighting
Step-Down (Buck) LED Drivers 3
MAX20078 PRODUCTION Synchronous Buck, High-Brightness LED Controller
MAX20096 PRODUCTION Dual-Channel Synchronous Buck, High-Brightness LED Controller with and without SPI Interface
MAX20097 RECOMMENDED FOR NEW DESIGNS Dual-Channel Synchronous Buck, High-Brightness LED Controller with and without SPI Interface
Modal heading
Add to myAnalog

Add product to the Products section of myAnalog (to receive notifications), to an existing project or to a new project.

Create New Project

Evaluation Kits

MAX25601EVKIT

Evaluation Kit for the MAX25601A, MAX25601B, MAX25601C, MAX25601D

Features and Benefits

  • Configured for Pre-Boost and Buck Application
  • Analog Dimming Control
  • Proven PCB Layout
  • Fully Assembled and Tested

Product Details

The MAX25601 evaluation kit (EV kit) provides a proven design to evaluate the MAX25601A/MAX25601C automotive high-voltage, high-brightness LED (HB LED) boost-buck controller. The front-end pre-boost operates from a 7.7V to 18V DC supply voltage, generating a 48V output. The buck supports 12x LEDs and lower, delivering up to 1.5A to one string of LEDs. The total voltage of the string can vary from 3V to 36V.

Applications

  • Automotive Exterior Lighting: High-Beam/Low-Beam/ Signal/Position Lights, Daytime Running Lights (DRLs), Matrix Light, Pixel Light, and Other Adaptive Front-Light Assemblies
  • Commercial, Industrial, and Architectural Lighting

MAX25601EVKIT
Evaluation Kit for the MAX25601A, MAX25601B, MAX25601C, MAX25601D
