MAX22514

Surge Protection IO-Link Device Transceiver with DC-DC

Show More showmore-icon

Low Power IO-Link Transceiver with Integrated High Efficiency DC/DC

Info : RECOMMENDED FOR NEW DESIGNS tooltip
Info : RECOMMENDED FOR NEW DESIGNS tooltip
Viewing: Part Details
arrow-icon
Part Details

Not the part you were looking for?

viewall Go to Product Selection Table
file View Data Sheet (Rev.0)
Open Interactive Page external-link
Documentation View All Documentation
IBIS Model MAX22514 IBIS Model Download 2.34MB
Part Models 4
1ku List Price Starting From $2.12
Features
  • High Configurability and Integration
    • IO-Link Device and Master Applications
    • COM1, COM2, and COM3 Data Rates
    • Integrated High-Efficiency 200mA DC-DC Buck Regulator
    • 200μA/2mA/5mA Current Sinks/Sources
    • C/Q Receiver is Configurable for 5V TTL
    • Highly Configurable Driver Overload Handling
    • Four Selectable Driver Slew Rates
    • SPI Configuration and Monitoring
    • Integrated Temperature Sensor
    • Configurable C/Q Driver: PNP, NPN, and PP Modes
  • Integrated Protection Enables Robust Systems
    • Integrated ±1kV/500Ω Surge Protection
    • Spread Spectrum DC-DC
    • Reverse Polarity Protection
    • Glitch Filter for Improved Burst Resilience
    • Hot-Plug Protection
  • Optimized for Small Sensor Designs
    • Accurate Oscillator for IO-Link Communication
    • 2.4Ω (typ) Driver On-Resistance for Low Power Dissipation
    • 1.2MHz DC-DC Switching Rate
    • Integrated 3.3V and 5V Linear Regulators
    • Available in Tiny WLP (2.5mm x 2.6mm) and TQFN (4mm x 5mm) Packages
Additional Details
show more Icon

The MAX22514 IO-Link transceiver integrates high voltage functionality, including one 24V line driver, an integrated DC-DC buck regulator, and 5V and 3.3V linear regulators. The MAX22514 is targeted for IO-Link devices, masters, and industrial switching sensor applications, and can be configured and monitored using a standard SPI interface.

Applications

  • IO-Link and Industrial Sensor and Actuator Devices
  • The MAX22514 features a SPI interface for configuration and diagnostics. A high level of integration (including two linear regulators, a DC-DC buck regulator, and integrated surge protection, combined with low power dissipation and small packages) optimizes the MAX22514 for use in many different industrial and IO-Link small sensor applications.
  • IO-Link Master Transceivers: The MAX22514 is capable of being used in both IOLink devices and IO-Link master applications. A SPI interface is used for extended configurability and diagnostics, and the transceiver is capable of operating at the COM1, COM2, and COM3 IO-Link data rates. The MAX22514 can be configured to enable the required 5mA pull-down/pull-up current on the C/Q line and generate a wake-up pulse.
Show More Arrow image
file View Data Sheet (Rev.0)
Documentation View All Documentation
IBIS Model MAX22514 IBIS Model Download 2.34MB
Part Models 4
1ku List Price Starting From $2.12
modal bookmark icon

{{modalTitle}}

modal close icon

{{modalDescription}}

{{dropdownTitle}}

input down arrow
  • {{defaultSelectedText}}
    • {{#each projectNames}}
  • {{name}}
    • {{/each}} {{#if newProjectText}}
  • plus icon {{newProjectText}}
    • {{/if}}
{{#if toggleButtonDescription}}
{{toggleButtonDescription}}
{{/if}} {{#if newProjectTitle}}

{{newProjectTitle}}

{{projectNameErrorText}}

{{/if}}

MAX22514

Documentation

2
overlayclose

Filters

1 Applied

mobileoverlaydownarrow
  • All
    TickIcon
  • Data Sheet
  • All
    TickIcon
  • English
  • Japanese
resetfilter

Reset Filters

Data Sheet

2

PDF Vector

PDF

PDF Vector

HTML

UPDATED 02/24/2022
English

MAX22514: Surge Protection IO-Link Device Transceiver with DC-DC Data Sheet (Rev.0)

Open PDF File

redirect
1.00M

Open Interactive Page

redirect
download

Download PDF

PDF Vector

PDF

UPDATED 02/24/2022
Japanese

MAX22514: DC/DC 内蔵のサージ保護付きIO-Link トランシーバー データシート (Rev.1)

Open PDF File

redirect
1.00M
download

Download PDF

There are no results matching this criteria. Try resetting your filters or searching for a different term

close icon
Documentation

Documentation

Webcast 2

Designing Industrial Connectivity Solutions for The Smart Factory
Design Considerations for IO-Link Industrial Smart Factory Sensors & Actuator

Video

1

Thumbnail Image

Video

2022-10-04

03:34

Introduction to the MAX22514 Surge Protected IO-Link Device Transceiver with DC-DC

Learn More
Show More Arrow image

ADI has always placed the highest emphasis on delivering products that meet the maximum levels of quality and reliability. We achieve this by incorporating quality and reliability checks in every scope of product and process design, and in the manufacturing process as well. "Zero defects" for shipped products is always our goal. View our quality and reliability program and certifications for more information.

Part Model Pin/Package Drawing Documentation CAD Symbols, Footprints, and 3D Models
MAX22514ATG+ 24-LFCSP-4X5X0.75 external-link
  • HTML
  • Material Declaration external-link
  • HTML
  • Reliablity Data external-link
MAX22514ATG+T 24-LFCSP-4X5X0.75 external-link
  • HTML
  • Material Declaration external-link
  • HTML
  • Reliablity Data external-link
MAX22514AWA+ 25-WLCSP-N/A external-link
  • HTML
  • Material Declaration external-link
  • HTML
  • Reliablity Data external-link
MAX22514AWA+T 25-WLCSP-N/A external-link
  • HTML
  • Material Declaration external-link
  • HTML
  • Reliablity Data external-link
Software & Part Ecosystem

Software & Part Ecosystem

Evaluation Kit

Evaluation Kits 1

reference details image

MAX22514EVKIT

Evaluation Kit for the MAX22514

zoom

MAX22514EVKIT

Evaluation Kit for the MAX22514

download icon

Download

 print icon

Print
MAX22514EVKIT
Evaluation Kit for the MAX22514

Features and Benefits

  • IO-Link-Compliant Device Transceiver
  • I/O and SPI Interface Terminals
  • Arduino® Uno Compatible Connector
  • Windows® 10-Compatible Software
  • USB-PC Connection
  • Proven PCB Layout
  • Fully Assembled and Tested
Buy Now View Details

Product Detail

The MAX22514 evaluation kit (EV kit) consists of the evaluation board and software. The EV kit is a fully assembled and tested circuit board that evaluates the MAX22514 IO-Link® device transceiver with integrated DC-DC buck regulator. The EV kit includes Windows®-compatible software that provides a graphical user interface (GUI) for exercising the features of the MAX22514. The EV kit is connected to a PC through a USB-A-to-micro-B cable.

Windows-based GUI software is available for use with the EV kit. Windows® 7 or newer Windows operating system is required to use the EV kit software.



Applications

  • IO-Link and Industrial Sensor and Actuator Devices
  • The MAX22514 features a SPI interface for configuration and diagnostics. A high level of integration (including two linear regulators, a DC-DC buck regulator, and integrated surge protection, combined with low power dissipation and small packages) optimizes the MAX22514 for use in many different industrial and IO-Link small sensor applications.
  • IO-Link Master Transceivers: The MAX22514 is capable of being used in both IO-Link devices and IO-Link master applications. A SPI interface is used for extended configurability and diagnostics, and the transceiver is capable of operating at the COM1, COM2, and COM3 IO-Link data rates. The MAX22514 can be configured to enable the required 5mA pull-down/pull-up current on the C/Q line and generate a wake-up pulse.

Resources

pdf icon

PDF

MAX22514EVKIT BOM Download

48.48K

pdf icon

PDF

MAX22514EVKIT Schematic Download

33.75K

pdf icon

ZIP

MAX22514EVKIT Design Files Download

3.04M

Show More Arrow image

Evaluation Kits1

evaluation kit item images

MAX22514EVKIT

Evaluation Kit for the MAX22514
Reference Designs

Reference Designs 1

Reference Designs1

MAXREFDES278: IO-Link 8-Channel Solenoid Actuator

MAXREFDES278

IO-Link 8-Channel Solenoid Actuator
