Overview

Features and Benefits

  • Small Solution
    • 2.35V to 5.50V Operating Supply Voltage
    • No External Component Required
    • 150µA Operating Current
  • High Precision
    • Selectable 102.5% to 110% OV Monitors
    • Selectable 97.5% to 90% UV Monitors
    • ±1% Accuracy
    • 0.5% Step Size
    • ASIL B Compliance
  • Highly Integrated
    • Five Fixed-Voltage Monitoring Inputs
    • Two Differential DVS Tracking-Voltage Monitoring Inputs with Remote-Ground Sense
    • Windowed Watchdog with Disable Pin for SoC Programming
    • Error-Correcting Code (ECC) on Internal OTP
    • Factory-Programmable Active-Low RESET Pin
  • 16-Pin Side-Wettable TQFN with Exposed Pad (3mm x 3mm)
  • AEC-Q100 Qualified
  • -40°C to +125°C Operating Temperature

Product Details

The MAX20481 is a complete ASIL-compliant SoC power system monitor with up to seven voltage-monitor inputs. Each input has factory OTP programmable OV/UV thresholds of between 2.5% and 10% with ±1% accuracy. Two of the inputs have a separate remote ground-sense input for use with high-current SoC supplies.

The MAX20481 contains a factory-programmable windowed watchdog with digital input pins for both refreshing and disabling the watchdog. The active-low RESET pin of the device can be set at the factory to assert under a variety of conditions.

The MAX20481 significantly reduces system size and component count while improving reliability compared to separate ICs or discrete components. The MAX20481 meets ASIL B reliability levels in a standalone application. The device is designed to operate from -40°C to +125°C ambient temperature.

Applications

  • Automotive ADAS Systems
  • Autonomous Driving Processing Systems
  • Power System Supervision and MCU/SoC Montioring
  • Remote Sensor Modules
