MAX20474
3.0V to 5.5V Input, 6V to 18V Output, Synchronous Boost Converter
Industry's Only Automotive AEC-Q100 Grade 1 Qualified Fully Synchronous 18V Boost Converter
Top
Overview
Features and Benefits
- Synchronous Boost Converter for Small Solution Size
- 4.0A Peak Input Current
- Resistor-Adjustable Output Voltage from 6V to 18V
- 6V to 18V Fixed Output Selection in 0.25V Steps
- 3.0V to 5.5V Operating Supply Voltage
- 2.2MHz Operation
- Active-Low RESET Output
- Spread Spectrum
- High Precision
- ±1.5% Output Voltage Accuracy, Fixed
- ±2.2% Output Voltage Accuracy, Adj
- 81 ± 3% UV Monitoring
- 121 ± 3% OV Monitoring
- Good Load-Transient Performance
- Robust for the Automotive Environment
- Current-Mode, Forced-PWM, and SKIP Operation
- Overtemperature and Short-Circuit Protection
- 3mm x 3.5mm, 14-Pin TDFN
- -40°C to +125°C Automotive Temperature Range
Product Details
The MAX20474 is a high-efficiency DC-DC converter that boosts 3.0V to 5.5V input supply from 6V to 18V at up to 1A load. The boost converter achieves ±1.5% output error over load, line, and temperature range.
The device features a 2.2MHz fixed-frequency PWM mode for better noise immunity and load-transient response, as well as a pulse-frequency modulation mode (skip) for increased efficiency during light-load operation. The 2.2MHz frequency operation allows for the use of all ceramic capacitors and minimizes external components. The programmable spread-spectrum frequency modulation minimizes radiated electromagnetic emissions. Integrated low RDSON switches improve efficiency at heavy loads and make planning the layout a much simpler task with respect to discrete solutions.
Other features include True Shutdown™, soft-start, overcurrent, and overtemperature protections.
Applications
- Automotive Point of Load
