Overview

Features and Benefits

  • Distortion-Free Beyond-the-Rails Signaling
    • Negative Voltage Audio and Video Signal Capable
    • -5.5V to +5.5V Analog Signal Range Independent of VCCEN
    • On-Resistance 0.19Ω (typ)
    • +1.6V to +5.5V Single-Supply Range
    • Total Harmonic Distortion Plus Noise -114dB (typ)
    • On-Resistance Flatness 0.0001Ω (typ)
  • Low Supply Current 65µA (typ) at 1.6V
    • Can be Powered by GPIO
    • High-Impedance Mode when VCCEN Not Applied
  • ESD Protection on COM_,NO_
    • ±30kV Human Body Model
    • ±7kV IEC 61000-4-2 Air Gap
    • ±8kV IEC 61000-4-2 Contact
  • Design Flexibility
    • 6-Bump WLP (1.308mm x 0.828mm) Package
    • 6-Pin FC2QFN (1.25mm x 1.75mm) Package
    • -40°C to +85°C Operating Temperature Range

Product Details

The MAX20336/MAX20337 ultra-small, low-on-resistance (RON) double-pole/single throw (DPST) analog switches feature Beyond-the-Rails™ capability that allows signals from -5.5V to +5.5V to pass without distortion, even when the power supply is below the signal range. The low onresistance (0.19Ω) also makes the devices ideal for lowdistortion switching applications, such as audio or video.

The MAX20336/MAX20337 are fully specified to operate from a single +1.6V to +5.5V power supply. Because of the low supply current requirement, VCCEN can be provided by a GPIO. When power is not applied, the switches go to a high-impedance mode and all analog signal ports can withstand signals from -5.5V to +5.5V.

The MAX20336/MAX20337 are available in a 1.308mm x 0.828mm, 0.4mm pitch, 6-bump wafer-level package (WLP) and 1.25mm x 1.75mm 6-pin FC2QFN package, and operate over the -40°C to +85°C extended temperature range.

Applications

  • Cell phone
  • Portable Audio/Video Equipment
  • Portable Navigation Devices
  • Tablet

Product Lifecycle icon-recommended Recommended for New Designs

This product has been released to the market. The data sheet contains all final specifications and operating conditions. For new designs, ADI recommends utilization of these products.
