MAX20010D

PRODUCTION

Automotive Single 6A Step-Down Converters

High-Accuracy, Fully Integrated and Synchronous 6A Converters with Flexible DVS

Data Sheet (Rev. 12)

Product Selection Table

Part Models: 16
1ku List Price: Starting From $1.44

Viewing:

Overview

Fully Integrated, Synchronous 6A DC-DC Converter Enables Small Solution Size
- 3.0V to 5.5V Operating Supply Voltage
High-Precision Voltage Regulator for Applications Processors
- ±2% Output-Voltage Accuracy
- Differential Remote Voltage Sensing
- I²C-Controlled Output Voltage of 0.5V to 1.27V in 10mV Steps, or 0.625V to 1.5875V in 12.5mV Steps
- Excellent Load-Transient Performance
Low-Noise Feature Reduces EMI
- 2.2MHz Operation
- Spread-Spectrum Option
- Frequency-Synchronization Input/Output
- Current-Mode, Forced-PWM, and Skip Operation
Robust for the Automotive Environment
- PGOOD Output
- Overtemperature and Short-Circuit Protection
- 20-Pin (4mm × 4mm) TQFN with an Exposed Pad
- -40°C to +125°C Operating Temperature Range
- AEC-Q100 Qualified

The MAX20010C/MAX20010D/MAX20010E ICs are high-efficiency, synchronous step-down converters that operate with a 3.0V to 5.5V input voltage range and provide a 0.5V to 1.5875V output voltage range. The wide input/output voltage range and the ability to provide up to 6A load current make these ICs ideal for on-board point-of-load and post-regulation applications. The ICs achieve ±2% output error over load, line, and temperature ranges. The MAX20010D/MAX20010E offers improved transient response.

The ICs feature a 2.2MHz fixed-frequency PWM mode for better noise immunity and load-transient response, and a pulse-frequency modulation mode (skip) for increased efficiency during light-load operation. The 2.2MHz frequency operation allows the use of all-ceramic capacitors and minimizes the solution footprint. The programmable spread-spectrum frequency modulation minimizes radiated electromagnetic emissions. Integrated low R_DS(ON) switches improve efficiency at heavy loads and make the layout a much simpler task with respect to discrete solutions.

The ICs are offered with factory-preset output voltages (see the Ordering Information for options). The I²C interface supports dynamic voltage adjustment with programmable slew rates. Other features include programmable soft-start, overcurrent, and overtemperature protections.

Part Models: 16
1ku List Price: Starting From $1.44

Documentation

Data Sheet 1

MAX20010C-MAX20010E: Automotive Single 6A Step-Down Converters Data Sheet (Rev.12) 10/22/2025
- Open Interactive Page

ADI has always placed the highest emphasis on delivering products that meet the maximum levels of quality and reliability. We achieve this by incorporating quality and reliability checks in every scope of product and process design, and in the manufacturing process as well. "Zero defects" for shipped products is always our goal. View our quality and reliability program and certifications for more information.

Part Model	Pin/Package Drawing	Documentation	CAD Symbols, Footprints, and 3D Models
MAX20010DATPN/V+	Thin Quad Flatpack, No Leads	Material Declaration Reliablity Data Package Resources	Ultra Librarian SamacSys
MAX20010DATPN/V+T	Thin Quad Flatpack, No Leads	Material Declaration Reliablity Data Package Resources	Ultra Librarian SamacSys
MAX20010DATPO/V+	Thin Quad Flatpack, No Leads	Material Declaration Reliablity Data Package Resources	Ultra Librarian SamacSys
MAX20010DATPO/V+T	Thin Quad Flatpack, No Leads	Material Declaration Reliablity Data Package Resources	Ultra Librarian SamacSys
MAX20010DATPO/VY+	20-LFCSP_SS-4X4X0.75	Material Declaration Reliablity Data Package Resources	Ultra Librarian SamacSys
MAX20010DATPO/VY+T	20-LFCSP_SS-4X4X0.75	Material Declaration Reliablity Data Package Resources	Ultra Librarian SamacSys
MAX20010DATPP/V+	Thin Quad Flatpack, No Leads	Material Declaration Reliablity Data Package Resources	Ultra Librarian SamacSys
MAX20010DATPP/V+T	Thin Quad Flatpack, No Leads	Material Declaration Reliablity Data Package Resources	Ultra Librarian SamacSys
MAX20010DATPQ/V+	Thin Quad Flatpack, No Leads	Material Declaration Reliablity Data Package Resources	Ultra Librarian SamacSys
MAX20010DATPQ/V+T	Thin Quad Flatpack, No Leads	Material Declaration Reliablity Data Package Resources	Ultra Librarian SamacSys
MAX20010DATPR/V+	Thin Quad Flatpack, No Leads	Material Declaration Reliablity Data Package Resources	Ultra Librarian SamacSys
MAX20010DATPR/V+T	Thin Quad Flatpack, No Leads	Material Declaration Reliablity Data Package Resources	Ultra Librarian SamacSys
MAX20010DATPT/V+	Thin Quad Flatpack, No Leads	Material Declaration Reliablity Data Package Resources	Ultra Librarian SamacSys
MAX20010DATPT/V+T	Thin Quad Flatpack, No Leads	Material Declaration Reliablity Data Package Resources	Ultra Librarian SamacSys
MAX20010DATPY/V+	Thin Quad Flatpack, No Leads	Material Declaration Reliablity Data Package Resources	Ultra Librarian SamacSys
MAX20010DATPY/V+T	Thin Quad Flatpack, No Leads	Material Declaration Reliablity Data Package Resources	Ultra Librarian SamacSys

Part Models	Product Lifecycle	PCN

Apr 16, 2021 - 2142 ASSEMBLY
		pcn_2142
MAX20010DATPN/V+	PRODUCTION
MAX20010DATPN/V+T	PRODUCTION
MAX20010DATPO/V+	PRODUCTION
MAX20010DATPO/V+T	PRODUCTION
MAX20010DATPO/VY+	PRODUCTION
MAX20010DATPO/VY+T	PRODUCTION
MAX20010DATPP/V+	PRODUCTION
MAX20010DATPQ/V+	PRODUCTION
MAX20010DATPR/V+	PRODUCTION
MAX20010DATPR/V+T	PRODUCTION
MAX20010DATPT/V+	PRODUCTION
MAX20010DATPT/V+T	PRODUCTION
Sep 29, 2020 - 1994 WAFER FAB
		pcn_1994
MAX20010DATPN/V+	PRODUCTION
MAX20010DATPN/V+T	PRODUCTION
MAX20010DATPO/V+	PRODUCTION
MAX20010DATPO/V+T	PRODUCTION
MAX20010DATPO/VY+	PRODUCTION
MAX20010DATPO/VY+T	PRODUCTION
MAX20010DATPP/V+	PRODUCTION
MAX20010DATPP/V+T	PRODUCTION
MAX20010DATPR/V+T	PRODUCTION
Apr 2, 2019 - 1924A ASSEMBLY
		pcn_1924a
MAX20010DATPO/VY+	PRODUCTION
MAX20010DATPO/VY+T	PRODUCTION

This is the most up-to-date revision of the Data Sheet.

Software Resources

Can't find the software or driver you need?

Request a Driver/Software

Tools & Simulations

EE-Sim Power® Tools 1

The EE-Sim DC-DC Converter Tool uses your requirements to quickly create a complete power design including a schematic, BOM with commercially available parts, and time and frequency domain simulations. Your customized schematic can be downloaded for further analysis in the standalone EE-Sim OASIS Simulator, featuring SIMPLIS and SIMetrix SPICE engines.

Start EE-Sim Now

Evaluation Kits

Evaluation Kit for MAX20010C/MAX20010D/ MAX20010E

Buy Now View Details

Features and Benefits

Differential Remote-Voltage Sensing
3V to 5.5V Input Supply Range
I²C-Controlled 0.5V to 1.5875V Output Voltage Range
2.2MHz Operation
±2% Output-Voltage Accuracy
Power-Good Output
Current-Mode, Forced-PWM, and Skip Operation
Proven PCB Layout
Fully Assembled and Tested

Product Details

The MAX20010 evaluation kit (EV kit) demonstrates the MAX20010 automotive single 6A step-down converter. The EV kit operates over an input range of 3V to 5.5V, with the output set for 1V and up to 6A load.
