MAX16147

High-Voltage Supervisors with Manual Reset Input

Show More showmore-icon

High-Voltage Supervisors with Manual Reset Input

Info : RECOMMENDED FOR NEW DESIGNS tooltip
Info : RECOMMENDED FOR NEW DESIGNS tooltip
Part Details
Part Models 2
1ku List Price Starting From $0.87
Features
  • Factory-Set Reset Threshold Options from +3.3V to +11.6V
  • Manual Reset Input
    • Active-High and Active-Low Trigger Options
    • Optional Internal Pullup or Pulldown
    • Fast (45µs) and Slow (50ms) Debounce Time Options
  • Guaranteed Reset Valid to VCC ≥ 1.3V
  • Push-Pull and Open-Drain Reset Output Options
    • MAX16143: Open-Drain, Active-Low
    • MAX16145: Open-Drain, Active-High
    • MAX16147: Push-Pull, Active-Low
    • MAX16149: Push-Pull, Active-High
  • Power-Supply Transient Immunity
  • -40°C to +125°C Operating Temperature Range
  • SOT23-5 Package and 4-Bump WLPs
Additional Details
show more Icon

The MAX16143, MAX16145, MAX16147, and MAX16149 are supervisory circuits that monitor their own supply voltages using a factory-set reset threshold that ranges from +3.3V to +11.6V. A manual reset (MR or active-low MR) input is included. The RESET (or active-low RESET) output has options for active-low, active-high, push-pull, or open-drain. The reset output asserts when the monitored voltage falls below the threshold voltage, and remains asserted until the monitored voltage has exceeded its threshold (plus hysteresis) for a time equal to the factory-set reset timeout period. Available reset timeout periods range from 30µs to 4.2s.

The 5-pin SOT23 and 4-bump wafer-level packages (WLPs) offer compatibility with space-constrained environments. These ICs are fully specified over the -40°C to +125°C temperature range.

Applications

  • Communications Equipment
  • Industrial Equipment
  • Servers
