MAX15162

8V to 60V Smart Dual 1.5A Circuit Breaker with Accurate Current Monitoring

Show More showmore-icon

Smallest Footprint, Smart High-Voltage Dual-Channel 1.5A eFuse

Info : RECOMMENDED FOR NEW DESIGNS tooltip
Info : RECOMMENDED FOR NEW DESIGNS tooltip
Part Details
Part Models 8
1ku List Price Starting From $1.25
Features
  • 8V to 60V Wide Input Voltage Range
  • Integrated Dual-Power MOSFET
  • Turn-On Resistance 140mΩ (WLP), 180mΩ (TQFN) MOSFET
  • Dual-Channel Independent or Parallel Mode Configuration
  • ± 3% Accuracy Current Reporting on Individual Channel
  • Enable Inputs for Individual Channels
  • Constant Power Control at Startup
  • Startup Watchdog Timer
  • Startup IN-to-OUT Short Protection
  • Undervoltage-Lockout
  • Overcurrent and Overtemperature Fault Status indication
  • Multilevel Overcurrent Limit Protection
  • Built in Thermal Shutdown Protection
  • Programmable Current Limiting Level
  • Programmable Overcurrent Shut-down Delay time
  • Programmable Auto-Retry Time (MAX15162A)
  • Latch Off in a Fault Event (MAX15162)
  • Auto-retry in a Fault Event (MAX15162A)
  • 24-pin, 4mm x 4mm TQFN or 16-bump, 2mm x 2mm WLP
Additional Details
show more Icon

The MAX15162/MAX15162A devices are dual-channel circuit-breaker ICs. The devices integrate a dual-channel controller with dual 140mΩ (in WLP, 180mΩ in TQFN) power MOSFETs and electronic circuit-breaker protection in a single package.

These devices feature constant power control during startup to keep the MOSFET operating under Safe Operating Area (SOA). The devices provide robust overcurrent protection with programmable current-limit level, and adjustable overcurrent shutdown delay for better immunity against system noises and load transient. The current monitoring pins provide a current sense accuracy of ±3% for each channel. When there is short-circuit at the output, a fast current limit comparator turns off MOSFETs within 200ns to isolate the load from the input. During a fault condition, the MAX15162A enters auto-retry mode and the MAX15162 enters latch off mode. For both devices, the ALRT pin asserts a fault indication. The MAX15162/MAX15162A can be configured as two independent channels or two parallel channels for one common output.

The devices feature a number of protection features including; IN-to-OUT short-circuit protection, output short-circuit protection, startup watchdog timer, input undervoltage lockout and internal overtemperature protection.

The MAX15162/MAX15162A are available in a 24-pin, 4mm x 4mm TQFN package and 16-bump, 2mm x 2mm WLP package and are rated over the -40°C to +105°C operation temperature range.

Applications

  • Communication
  • Industrial
  • Radio Access Point System
Part Models 8
1ku List Price Starting From $1.25

close icon
Documentation

Documentation

Video

Part Model Pin/Package Drawing Documentation CAD Symbols, Footprints, and 3D Models
MAX15162AATG+
  • HTML
  • HTML
MAX15162AATG+T
  • HTML
  • HTML
MAX15162AAWE+
  • HTML
  • HTML
MAX15162AAWE+T
  • HTML
  • HTML
MAX15162ATG+
  • HTML
  • HTML
MAX15162ATG+T
  • HTML
  • HTML
MAX15162AWE+
  • HTML
  • HTML
MAX15162AWE+T
  • HTML
  • HTML
Software & Part Ecosystem

Software & Part Ecosystem

Evaluation Kit

Evaluation Kits 3

MAX15162AWEEVKIT

Evaluation Kit for MAX15162

zoom

MAX15162AWEEVKIT

Evaluation Kit for MAX15162

Evaluation Kit for MAX15162

Features and Benefits

  • 8V to 60V Wide Input Voltage Range
  • Integrated Dual-Power MOSFET with Low Turn-on Resistance 150mΩ
  • Dual-Channel Independent or Parallel Mode Configuration
  • Undervoltage Lockout
  • Enable Input for Individual Channel
  • Constant Power Control at Startup
  • Startup Watchdog Timer
  • Startup IN-to-OUT Short Protection
  • Overcurrent and Overtemperature Fault Status Indication on Individual Channel
  • ±3% Accuracy Current Reporting on Individual Channel
  • Multilevel Overcurrent Limit Protection
  • Programmable Current-Limit Level
  • Programmable Overcurrent Shutdown Delay Time
  • Latch in a Fault Event (MAX15162AWE+)
  • Auto-Retry in a Fault Event with Programmable Auto-Retry Time (MAX15162AAWE+)
  • Built-in Thermal Shutdown Protection
  • Proven PCB Layout
  • Fully Assembled and Tested

Product Detail

The MAX15162AWE evaluation kit (EV kit) is a fully assembled and tested surface-mount circuit board that contains all components necessary to evaluate the MAX15162AWE+ and MAX15162AAWE+ dual-channel circuit breaker IC for power amplifier system. The IC is in an extremely compact, 16-bump, 2mm x 2mm WLP. The EV kit is powered from an 8V to 60V DC supply and can be configured as two independent single-channel or one parallel dual-channel circuit breaker. The EV kit provides multilevel overcurrent limit protection and pin-strap programmable current-limit level up to 1.5A for each channel.

The EV kit demonstrates the full functionality of the MAX15162AWE+/MAX15162AAWE+, such as IN-OUT short protection during startup, inrush current control, input undervoltage lockout (UVLO), programmable overcurrent shutdown delay time and fast large overcurrent protection. The EV kit also features current monitoring/reporting with ±3% accuracy (0.8A~1.5A) on individual channel and overcurrent/overtemperature fault status indication.

MAX15162TAEVKIT

Evaluation Kit for the MAX15162

zoom

MAX15162TAEVKIT

Evaluation Kit for the MAX15162

Evaluation Kit for the MAX15162

Features and Benefits

  • 8V to 60V Wide Input Voltage Range
  • Integrated Dual-Power MOSFET with Turn-on Resistance 200mΩ
  • Dual-Channel Independent or Parallel Mode Configuration
  • Undervoltage Lockout
  • Enable Input for Individual Channel
  • Constant Power Control at Startup
  • Startup Watchdog Timer
  • Startup IN-to-OUT Short Protection
  • Over-current and Overtemperature Fault Status Indication on Individual Channel
  • ±3% Accuracy Current Reporting on Individual Channel
  • Multi-Level Overcurrent Limit Protection
  • Programmable Current Limit Level
  • Programmable Overcurrent Shutdown Delay Time
  • Latch in a Fault Event (MAX15162ATG+)
  • Auto-Retry in a Fault Event with Programmable Auto-Retry Time (MAX15162AATG+)
  • Built-In Thermal Shutdown Protection
  • Proven PCB Layout
  • Fully Assembled and Tested

Product Detail

The MAX15162ATG evaluation kit (EV kit) is a fully assembled and tested surface-mount circuit board that contains all components necessary to evaluate the MAX15162ATG+/MAX15162AATG+ dual-channel circuit breaker IC for power amplifier system. The IC is in compact 24-pin, 4mm x 4mm TQFN package. The EV kit is powered from an 8V to 60V DC supply and can be configured as two independent single-channels or one parallel dual-channel circuit breaker. The EV kit provides multilevel overcurrentlimit protection and pin-strap programmable current-limit level up to 1.5A for each channel.

The EV kit demonstrates the full functionality of the MAX15162ATG+/MAX15162AATG+, such as IN-OUT short protection during startup, inrush current control, input undervoltage-lockout (UVLO), programmable overcurrent shutdown delay time and fast large overcurrent protection. The EV kit also features current monitoring/ reporting with ±3% accuracy (0.8~1.5A) on individual channel and overcurrent/overtemperature fault status indication.

Applications

  • Communication
  • Industrial
  • Radio Access Point System

MAX15162TLEVKIT

Evaluation Kit for the MAX15162

zoom

MAX15162TLEVKIT

Evaluation Kit for the MAX15162

Evaluation Kit for the MAX15162

Features and Benefits

  • 8V to 60V Wide Input Voltage Range
  • Integrated Dual-Power MOSFET with Turn-on Resistance 200mΩ
  • Dual-Channel Independent or Parallel Mode Configuration
  • Undervoltage Lockout
  • Enable Input for Individual Channel
  • Constant Power Control at Startup
  • Startup Watchdog Timer
  • Startup IN-to-OUT Short Protection
  • Over-current and Overtemperature Fault Status Indication on Individual Channel
  • ±3% Accuracy Current Reporting on Individual Channel
  • Multi-Level Overcurrent Limit Protection
  • Programmable Current Limit Level
  • Programmable Overcurrent Shutdown Delay Time
  • Latch in a Fault Event (MAX15162ATG+)
  • Auto-Retry in a Fault Event with Programmable Auto-Retry Time (MAX15162AATG+)
  • Built-In Thermal Shutdown Protection
  • Proven PCB Layout
  • Fully Assembled and Tested

Product Detail

The MAX15162ATG evaluation kit (EV kit) is a fully assembled and tested surface-mount circuit board that contains all components necessary to evaluate the MAX15162ATG+/MAX15162AATG+ dual-channel circuit breaker IC for power amplifier system. The IC is in compact 24-pin, 4mm x 4mm TQFN package. The EV kit is powered from an 8V to 60V DC supply and can be configured as two independent single-channels or one parallel dual-channel circuit breaker. The EV kit provides multilevel overcurrentlimit protection and pin-strap programmable current-limit level up to 1.5A for each channel.

The EV kit demonstrates the full functionality of the MAX15162ATG+/MAX15162AATG+, such as IN-OUT short protection during startup, inrush current control, input undervoltage-lockout (UVLO), programmable overcurrent shutdown delay time and fast large overcurrent protection. The EV kit also features current monitoring/ reporting with ±3% accuracy (0.8~1.5A) on individual channel and overcurrent/overtemperature fault status indication.

Applications

  • Communication
  • Industrial
  • Radio Access Point System
Tools & Simulations

Tools & Simulations 1

LTspice® is a powerful, fast and free simulation software, schematic capture and waveform viewer with enhancements and models for improving the simulation of analog circuits.
