MAX14915

Compact Industrial Octal High-Side Switch with Diagnostics

Show More showmore-icon

Industry's Smallest Octal Industrial High Side Switch with Diagnostics

Info: : PRODUCTION tooltip
Info: : PRODUCTION tooltip
Part Details
Part Models 2
1ku List Price Starting From $5.21
Features
  • Robustness and Smart Diagnostics
    • 65V Absolute Maximum Supply Range
    • Internal Clamps for Fast Inductive Load Demagnetization
    • CRC Error Checking on the SPI Interface
    • Watchdog Timer for Diagnostics Checking
    • Open-Wire Detection, Both with Switches On and Off
    • Undervoltage Detection with UVLO
    • Loss of VDD or GND Protection
    • Thermal Shutdown Protection
    • Integrated ±1kV/42Ω IEC61000-4-5 Surge Protection
    • -40°C to +125°C Operating Ambient Temperature
  • Reduces Power and Heat Dissipation
    • 250mΩ (Max) On-Resistance at TA = 125°C
    • 2mA (typ) Supply Current
    • Accurate Output Current Limiting
  • Flexibility
    • Addressable SPI Interface Reduces Isolation Cost
    • SYNCH Input for Simultaneous Update of Switches
    • LED Driver Matrix for 16 LEDs, Powered by 24V, 5V, or 3.3V
    • Flexible Logic Voltage Interface from 2.5V to 5.5V
  • Compact 6mm x 6mm QFN Package
Additional Details
show more Icon

The MAX14915 has eight high-side switches specified to deliver up to 700mA continuous current. The high-side switches have on-resistance of 250mΩ (max) at 125°C ambient temperature.

The SPI interface has a built-in chip addressing decoder, allowing communication with multiple MAX14915s utilizing a common SPI chip select (active-low CS).

The SPI interface provides flexibility for global and per-channel configuration and diagnostic, including over and undervoltage detection, open wire/load detection, overload and current limiting reporting, thermal conditions reporting, and more.

Open load detection detects both open-wire/open-load conditions with switches in the on and off states. LED drivers provide indication of per-channel fault, status, and supply undervoltage conditions. Internal active clamps allow for fast turn-off of inductive loads.

Integrated line-to-ground and line-to-line surge protection only requires a TVS on VDD.

The MAX14915 is available in a compact 48-pin 6mm x 6mm QFN package.

Applications

  • Industrial Digital Outputs
  • PLC Systems
Part Models 2
1ku List Price Starting From $5.21

close icon
Documentation

Documentation

Video

Part Model Pin/Package Drawing Documentation CAD Symbols, Footprints, and 3D Models
MAX14915AFM+
  • HTML
  • HTML
MAX14915AFM+T
  • HTML
  • HTML
Software & Part Ecosystem

Software & Part Ecosystem

Evaluation Kit

Evaluation Kits 1

reference details image

MAX14915EVKIT

Evaluation Kit for the MAX14915

zoom

MAX14915EVKIT

Evaluation Kit for the MAX14915

Evaluation Kit for the MAX14915

Features and Benefits

  • Robust Operation with Wide Range Of Input Voltages and Load Conditions
  • VDDOK Indication
  • LED Indication of Channels Status and Fault Conditions
  • Fast Inductive Load Demagnetization
  • Open-wire, Overload, Undervoltage, Overcorrect, Thermal Shutdown Fault Conditions Indication
  • Supports Watchdog and SYNCH Features
  • Communication Error Indication
  • Wide Logic Voltage Range
  • Pin Addressable SPI Communication
  • -40°C to +125°C Temperature Range
  • Proven PCB Layout
  • Fully Assembled and Tested
  • Windows 10 Compatible Software

Product Detail

The MAX14915 evaluation kit (EV kit) provides a proven design to evaluate the MAX14915, octal high-side switch with extended diagnostics. The EV kit includes the MAX14915 evaluation board and a graphical user interface (GUI) that provides communication from a PC to the target device through a USB port and the USB2GPIO interface board. The USB2GPIO EV kit should be ordered separately.

The GUI is compatible with Windows 10 for exercising the features of the MAX14915 IC. The EV kit GUI allows individually controlling of eight high-side switches through the high-speed SPI interface and receive a diagnostic information from the MAX14915, including open-wire/ open-load conditions, state of the output channels, multiple undervoltage alarms, global and per channel overtemperature alarms, and multiple fault alarms.

The MAX14915 EV kit must be powered from an external +24V power supply and can consume more than 10A when fully loaded. The USB2GPIO interface board is powered from the USB port.

The MAX14915 EV kit board comes with a MAX14915AFM+ installed in a 48-pin, 6 x 6mm FC2QFN package.

Applications

  • Industrial Digital Outputs
  • PLC Systems
