DS28CM00
I²C/SMBus Silicon Serial Number
Show More
Unique 64-bit factory lasered in each part. Perfect low-cost solution for embedded applications requiring an electronic serial number.
Not the part you were looking for?
Ask a Question
Submit your question below and we will return the best answer from ADI’s knowledge database:
Search
Other places you can find help
Support
Analog Devices Support Portal is a one-stop shop to answer all your ADI questions.
Visit the ADI Support Page
Features
- Unique, Factory-Lasered and Tested 64-bit Registration Number (8-bit Family Code + 48-bit Serial Number + 8-bit CRC)
- SMBus-Compatible I²C Serial Interface
- Supports 100kHz and 400kHz Communication Speeds
- 5V Tolerant Interface Pins
- Operating Range: 1.8V ±10% to 5V ±5%, -40°C to +85°C
- 5-Pin SOT23 Package
.svg?rev=fd385c90e2cf4716ae9a8c8d20e6b8e3&la=en&h=24&w=24&hash=A302DF48F94BAAA11877AF223F27157A){kind=icon}
The DS28CM00 is a low-cost, electronic registration number to provide an absolutely unique identity that can be determined with the industry standard I²C and SMBus™ interface. The registration number is a factory-lasered, 64-bit ROM that includes a unique 48-bit serial number, an 8-bit CRC, and an 8-bit family code (70h). In SMBus mode, the DS28CM00 resets its communication interface if it detects a bus fault condition.
Applications
- Accessory and Peripheral Identification
- Equipment Registration and License Management
- Network Node Identification
- Printed Circuit Board Unique Serialization
Ask a Question
Submit your question below and we will return the best answer from ADI’s knowledge database:
Search
Other places you can find help
Support
Analog Devices Support Portal is a one-stop shop to answer all your ADI questions.
Visit the ADI Support Page
{{modalTitle}}
{{modalDescription}}
{{dropdownTitle}}
- {{defaultSelectedText}} {{#each projectNames}}
- {{name}} {{/each}} {{#if newProjectText}}
-
{{newProjectText}}
{{/if}}
{{newProjectTitle}}
{{projectNameErrorText}}
DS28CM00
Documentation
Filters
1 Applied
-
All
-
Reliability Data
-
Data Sheet
-
All
-
English
-
Chinese
-
Japanese
Data Sheet
3
Reliability Data
1
11.93K
Documentation
Data Sheet 1
Reliability Data 1
ADI has always placed the highest emphasis on delivering products that meet the maximum levels of quality and reliability. We achieve this by incorporating quality and reliability checks in every scope of product and process design, and in the manufacturing process as well. "Zero defects" for shipped products is always our goal. View our quality and reliability program and certifications for more information.
| Part Model | Pin/Package Drawing | Documentation | CAD Symbols, Footprints, and 3D Models |
|---|---|---|---|
| DS28CM00R-A00+T |
5-SOT_23-N/A
|
|
|
| DS28CM00R-A00+U |
5-SOT_23-N/A
|
|
- DS28CM00R-A00+T
- Pin/Package Drawing
-
5-SOT_23-N/A
- Documentation
-
HTML
Material Declaration
-
HTML
Reliablity Data
- CAD Symbols, Footprints, and 3D Models
-
Ultra Librarian
-
SamacSys
- DS28CM00R-A00+U
- Pin/Package Drawing
-
5-SOT_23-N/A
- Documentation
-
HTML
Material Declaration
-
HTML
Reliablity Data
- CAD Symbols, Footprints, and 3D Models
-
Ultra Librarian
-
SamacSys
Filter by Model
Part Models
Product Lifecycle
PCN
Feb 4, 2015
- 1341_CANCELLATION
ASSEMBLY
DS28CM00R-A00+T
PRODUCTION
DS28CM00R-A00+U
PRODUCTION
Jan 11, 2021
- 1703RN
ASSEMBLY
DS28CM00R-A00+U
PRODUCTION
Filter by Model
Part Models
Product Lifecycle
PCN
Feb 4, 2015
- 1341_CANCELLATION
ASSEMBLY
Jan 11, 2021
- 1703RN
ASSEMBLY
Software & Part Ecosystem
| Parts | Product Life Cycle | Description | ||
|---|---|---|---|---|
|
1-Wire Memory (EPROM, EEPROM, ROM)1 |
||||
|
RECOMMENDED FOR NEW DESIGNS |
Silicon Serial Number with or without VCC Input |
|||
Evaluation Kits 1
DS28CM00EVKIT
Evaluation Board/Evaluation System for the DS28CM00
Product Detail
The DS28CM00 evaluation system (EV system) consists of a DS28CM00 evaluation board (EV board) and a Maxim CMAXQUSB command module. The DS28CM00 is a low-cost, electronic registration number providing an absolutely unique identity that can be determined with the industry-standard I²C and SMBus™ interface. The registration number is a factory-lasered, 64-bit ROM that includes a unique 48-bit serial number, an 8-bit CRC, and an 8-bit family code. The evaluation software runs under Windows XP® or Windows® 2000 operating system (OS), providing a handy user interface to exercise the features of the DS28CM00.
Order the DS28CM00EVKIT for the complete EV system to evaluate the DS28CM00 using a PC. Evaluation software for the EV system is also available on our website at: www.maximintegrated.com/EVkitsoftware.
Applications
- Accessory and Peripheral Identification
- Equipment Registration and License Management
- Network Node Identification
- Printed Circuit Board Unique Serialization
