ADV611-ADV612

NOT RECOMMENDED FOR NEW DESIGNS

Closed Circuit TV Digital Video Codec

Data Sheet (Rev. 0) Product Selection Table

Viewing:

Overview

Programmable Quality Box
Industrial Temperature Range (ADV612)
Hardware Frame Rate Reduction

100% Bitstream Compatible with with the ADV601 and ADV601LC
Precise Compressed Bit Rate Control
General Purpose 16- or 32-bit Host Interface with 512 Deep 32-bit FIFO
See data sheet for additional features

The ADV611 and ADV612 are a low cost, single chip, dedicated function, all digital CMOS VLSI devices capable of supporting visually loss-less to 7500:1 real-time compression and decompression of CCIR-601 digital video at very high image quality levels. The chips integrate glueless video and host interfaces with on-chip SRAM to permit low part count, system level implementations suitable for a broad range of applications. The ADV611 and ADV612 are 100% bitstream compatible with the ADV601.
