ADSP-2161
alert :
Obsolete
alert :
Obsolete
Part Details
Part Details
Not the part you were looking for?
Ask a Question
Submit your question below and we will return the best answer from ADI’s knowledge database:
Search
Other places you can find help
Support
Analog Devices Support Portal is a one-stop shop to answer all your ADI questions.
Visit the ADI Support Page
Features
- 25 MIPS, 40 ns Maximum Instruction Rate (5 V)
- Separate On-Chip Buses for Program and Data Memory
- Program Memory Stores Both Instructions and Data (Three-Bus Performance)
- Dual Data Address Generators with Modulo and Bit-Reverse Addressing
- Efficient Program Sequencing with Zero-Overhead Looping: Single-Cycle Loop Setup
- Double-Buffered Serial Ports with Companding Hardware, Automatic Data Buffering and Multichannel Operation
- Three Edge- or Level-Sensitive Interrupts
- Low Power IDLE Instruction
- PLCC and MQFP Packages
Additional Details
.svg?rev=fd385c90e2cf4716ae9a8c8d20e6b8e3&la=en&h=24&w=24&hash=A302DF48F94BAAA11877AF223F27157A){kind=icon}
The ADSP-216x processors provide the option of custom ROM programming to users of ADSP-2100 Family devices. Pin compatible to the ADSP-2101, -2115, and -2105, the ADSP-216x family can reduce system cost in these designs by eliminating the need for any external memory devices.
