Overview

Features and Benefits

  • Low input voltage range:
    1.4 V to 3.6 V
  • Power Switch: Low RDSON of 160 mΩ at 1.8 V, with Active Discharge
  • SPST NO Signal Switches (4) :
    RDSON of 2 Ω at 1.8 V with active pull down on one side
  • 500 mA continuous operating current
  • Built-in level shift for control logic that can be operated by 1.2V logic
  • Ultralow shutdown current: < 0.7 μA
  • Ultrasmall 1.2 mm × 1.6mm × 0.6mm, 12-ball, 0.4 mm pitch WLCSP

Product Details

The ADP1190 is an integrated high-side load switch with 4 signal switches designed for operation from 1.4 V to 3.6 V. This load switch provides power domain isolation for extended power battery life. The load switch is a low on-resistance P-channel MOSFET that supports up to 500 mA of continuous load current and minimizes power loss. Integrated with the load switch are 4 normally open two Ohm SPST signal switches.

Beyond operating performance, the ADP1190 occupies minimal printed circuit board (PCB) space with an area less than 1.92 mm2 and a height of 0.60 mm. The ADP1190 is available in an ultrasmall 1.2 mm × 1.6 mm, 12-ball, 0.4 mm pitch WLCSP.

APPLICATIONS

  • Mobile phones
  • SIM Card Disconnect switch
  • Digital cameras and audio devices
  • Portable and battery-powered equipment

Product Lifecycle icon-recommended Production

At least one model within this product family is in production and available for purchase. The product is appropriate for new designs but newer alternatives may exist.

Design Resources

ADI has always placed the highest emphasis on delivering products that meet the maximum levels of quality and reliability. We achieve this by incorporating quality and reliability checks in every scope of product and process design, and in the manufacturing process as well.  "Zero defects" for shipped products is always our goal.View our quality and reliability program and certifications for more information.

Part Number Material Declaration Reliability Data Pin/Package Drawing CAD Symbols, Footprints & 3D Models
ADP1190ACBZ-R7 Material Declaration Reliability Data 12-Ball WLCSP (1.2mm x 1.6mm)
