ADM207

PRODUCTION

0.1 µF, +5V CMOS RS-232 200kBPS Transceiver with 5 Drivers & 3 Receivers

Data Sheet (Rev. D) Product Selection Table

Part Models: 5
1ku List Price: Starting From $1.99

Viewing:

Part Details

0.1 µF to 10 µF Capacitors
120 kB/s Data Rate
Two Receivers Active in Shutdown (ADM213)
On-Board DC-to-DC Converters
±9 V Output Swing with 5 V Supply

Low Power (15 mW)
Low Power Shutdown ≤ 5 µW
±30 V Receiver Input Levels
Latch-Up FREE
Plug-In Upgrade for MAX205-211/213

Part Models: 5
1ku List Price: Starting From $1.99
