Features and Benefits

  • 0.58 Ω typical on resistance
  • 0.82 Ω maximum on resistance at 85°C
  • 1.8 V to 5.5 V single supply
  • High current carrying capability: 250 mA continuous
  • Rail-to-rail switching operation
  • Fast-switching times: <20 ns
  • Typical power consumption: <0.1 μW
  • 2.1 mm × 2.1 mm mini LFCSP

Product Details

The ADG858 is a low voltage CMOS device containing four single-pole, double-throw (SPDT) switches. This device offers ultralow on resistance of less than 0.82 Ω over the full temperature range. The ADG858 is fully specified for 4.2 V to 5.5 V and 2.7 V to 3.6 V supply operation.

Each switch conducts equally well in both directions when on and has an input signal range that extends to the supplies. The ADG858 exhibits break-before-make switching action.

The ADG858 is available in a 2.1 mm × 2.1 mm, 16-lead mini LFCSP. This tiny package makes the device ideal for spaceconstrained applications, such as handsets, PDAs, and MP3s.

Product Highlights

  1. <0.82 Ω over the full temperature range of −40°C to +85°C.
  2. Single 1.8 V to 5.5 V operation.
  3. Compatible with 1.8 V CMOS logic.
  4. High current handling capability (250 mA continuous current per channel).
  5. Low THD + N: 0.06% typical.
  6. 2.1 mm × 2.1 mm, 16-lead mini LFCSP.

Applications

  • Cellular phones
  • PDAs
  • MP3 players
  • Power routing
  • Battery-powered systems
  • PCMCIA cards
  • Modems
  • Audio and video signal routing
  • Communication systems
