Features and Benefits
- Latch-up proof
- 3 pF off source capacitance
- 26 pF off drain capacitance
- −0.6 pC charge injection
- Low leakage: 0.4 nA maximum at 85ºC
- ±9 V to ±22 V dual-supply operation
- 9 V to 40 V single-supply operation
- 48 V supply maximum ratings
- Fully specified at ±15 V, ±20 V, +12 V, and +36 V
- VSS to VDD analog signal range
The ADG5204 is a complementary metal oxide semiconductor (CMOS) analog multiplexer, comprising four single channels.
The ultralow capacitance and charge injection of these switches make them ideal solutions for data acquisition and sample-and-hold applications, where low glitch and fast settling are required. Fast switching speed together with high signal bandwidth make the ADG5204 suitable for video signal switching.
The ADG5204 is designed on a trench process, which guards against latch-up. A dielectric trench separates the P and N channel transistors, thereby preventing latch-up even under severe overvoltage conditions. The ADG5204 switches one of four inputs to a common output, D, as determined by the 3-bit binary address lines, A0, A1, and EN. Logic 0 on the EN pin disables the device. Each switch conducts equally well in both directions when on, and each switch has an input signal range that extends to the supplies. In the off condition, signal levels up to the supplies are blocked. All switches exhibit break-before-make switching action.
- Automatic test equipment
- Data acquisition
- Audio and video switching
- Communication systems
- Trench Isolation Guards Against Latch-Up. A dielectric trench separates the P and N channel transistors, thereby preventing latch-up even under severe overvoltage conditions.
- Ultralow capacitance and < 1 pC charge injection.
- Dual-Supply Operation. For applications where the analog signal is bipolar, the ADG5204 can be operated from dual supplies up to ±22 V.
- Single-Supply Operation. For applications where the analog signal is unipolar, the ADG5204 can be operated from a single rail power supply up to 40 V.
- 3 V Logic Compatible Digital Inputs.
- VINH = 2.0 V, VINL = 0.8 V.
- No VL Logic Power Supply Required.
Markets and Technologies
Product Lifecycle Recommended for New Designs
This product has been released to the market. The data sheet contains all final specifications and operating conditions. For new designs, ADI recommends utilization of these products.
Evaluation Kits (1)
The EVAL-14TSSOPEBZ evaluation board evaluates 14-lead TSSOP devices in the Switches and Multiplexers Portfolio that must be purchased separately from the evaluation board. A clamp is supplied with the EVAL-14TSSOPEBZ to secure a 14-lead TSSOP device to the evaluation board without the need for soldering, making the board reusable for multiple devices.
A 14-lead TSSOP device can be clamped or soldered to the center of the evaluation board. Each pin of the device that the eval board evaluates has a corresponding link from K1 to K14 that can be set to either VDD or GND. A wire screw terminal supplies VDD and GND. SMB connectors on the board allow additional external signals to be supplied to the device. In addition, there is space available at the top of the board for prototyping.
For full details, see the corresponding product data sheet, which must be used in conjunction with this user guide when using the evaluation board.
