AD9963/AD9961-EBZ Evaluation Board7/3/2012
Features and Benefits
- Dual 10-bit/12-bit, 100 MSPS ADC SNR = 67 dB, fIN = 30.1 MHz
- Dual 10-bit/12-bit, 170 MSPS DAC ACLR = 74 dBc
- 5 channels of analog auxiliary input/output
- Low power, <425 mW at maximum sample rates
- Supports full and half-duplex data interfaces
- Small 72-lead LFCSP lead-free package
The AD9961/AD9963 are pin-compatible, 10-/12-bit, low power MxFE® converters that provide two ADC channels with sample rates of 100 MSPS and two DAC channels with sample rates to 170 MSPS. These converters are optimized for transmit and receive signal paths of communication systems requiring low power and low cost. The digital interfaces provide flexible clocking options. The transmit is configurable for 1×, 2×, 4×, and 8× interpolation. The receive path has a bypassable 2× decimating low-pass filter.
The AD9961 and AD9963 have five auxiliary analog channels. Three are inputs to a 12-bit ADC. Two of these inputs can be configured as outputs by enabling 10-bit DACs. The other two channels are dedicated outputs from two independent 12-bit DACs.
The high level of integrated functionality, small size, and low power dissipation of the AD9961/AD9963 make them well- suited for portable and low power applications.
- Wireless infrastructure Picocell, femtocell basestations
- Medical instrumentation Ultrasound AFE
- Portable instrumentation Signal generators, signal analyzers
Product Lifecycle Recommended for New Designs
This product has been released to the market. The data sheet contains all final specifications and operating conditions. For new designs, ADI recommends utilization of these products.
Evaluation Kits (2)
This page contains evaluation board documentation and ordering information for evaluating the AD9963.
The DPGI/O provides pattern generation and receiving capabilities to compliment several evaluation boards from Analog Devices. The DPGI/O connects to a PC over USB, and allows a user to download a vector from their PC into the DPGI/O’s internal memory, or to receive a vector from an evaluation board and transfer it to the PC.
Analog Devices' pattern generator/receivers and evaluation boards are designed and sold solely to support an efficient and thorough means by which to evaluate Analog Devices components in a lab environment for a wide range of end applications. Any application or use of the pattern generators and/or evaluation boards, other than specified above, will not be supported.
Documentation & Resources
Software & Systems Requirements
Tools & Simulations
ADI has always placed the highest emphasis on delivering products that meet the maximum levels of quality and reliability. We achieve this by incorporating quality and reliability checks in every scope of product and process design, and in the manufacturing process as well. "Zero defects" for shipped products is always our goal.View our quality and reliability program and certifications for more information.
|Part Number||Material Declaration||Reliability Data||Pin/Package Drawing||CAD Symbols, Footprints & 3D Models|
|AD9963BCPZ||Material Declaration||Reliability Data||72-Lead LFCSP (10mm x 10mm w/ EP)|
|AD9963BCPZRL||Material Declaration||Reliability Data||72-Lead LFCSP (10mm x 10mm w/ EP)|
|Wafer Fabrication Data|
