AD9843A

Obsolete

Complete 10-Bit, 20 MHz CCD Signal Processor

Data Sheet (Rev. 0) Product Selection Table

Viewing:

Part Details

20 MHz Correlated Double Sampler (CDS)
0 to 34 dB Variable Gain Amplifier (VGA)
Pre-Blanking Function
Low-Noise Clamp Circuits
10-bit 20 MSPS A/D Converter

No Missing Codes Guaranteed
Auxiliary Inputs available
3-Wire Serial Digital Interface
+3 V Single Supply Operation
Low Power CMOS: 75 mW
48-Lead LQFP Package

Suggested Replacement Parts

Complete, 12-Bit, 45 MHz CCD Signal Processor

Documentation

Data Sheet 1

AD9843A: Complete 10-Bit 20 MSPS CCD Signal Processor Data Sheet (Rev.0) 10/30/2000

Application Note 1

AN-297: Test Video A/D Converters Under Dynamic Conditions 09/06/2002

Technical Articles 2

Analog Exposes Front End for Digital Cameras 01/05/2000

High Integration Simplifies Signal Processing For CCDs 02/23/1998

This is the most up-to-date revision of the Data Sheet.
