AD9804

Complete 10-Bit, 18 MHz CCD Signal Processor

Show More showmore-icon

alert : Obsolete tooltip
alert : Obsolete tooltip
Part Details
Part Models 2
1ku List Price
price unavailable
Features
  • 18 MHz Correlated Double Sampler (CDS)
  • 0 to 34 dB Variable Gain Amplifier (VGA)
  • Pre-Blanking Function
  • 10-bit 18 MSPS A/D Converter
  • No Missing Codes Guaranteed
  • 3-Wire Serial Digital Interface
  • +3 V Single Supply Operation
  • Low Power CMOS: 85 mW
  • 48-Lead LQFP Package
Additional Details
show more Icon

The AD9804 is a complete Analog Front-End (AFE) product for low-cost CCD camera applications. It features the basic circuitry necessary to sample, condition, and digitize the analog output of interlaced and progressive scan area CCDs. The VGA gain is variable from 0 to 34 dB and is programmed through a 3-Wire serial digital interface.

Part Models 2
1ku List Price
price unavailable

close icon
Documentation

Documentation

Part Model Pin/Package Drawing Documentation CAD Symbols, Footprints, and 3D Models
AD9804AJSTZ
  • HTML
  • HTML
AD9804AJSTZRL
  • HTML
  • HTML

Filter by Model

reset

Reset Filters

Part Models

Product Lifecycle

PCN

Oct 18, 2016

- 16_0034

Assembly Relocation of Select LQFP,LQFP_EP,MQFP,TQFP,TQFP_EP Products to Stats ChipPAC China Jiangyin

Oct 21, 2009

- 09_0097

Assembly Site Transfer of 48L 7x7 LQFP Package from Carsem, Malaysia to STATS ChipPAC-China (SCC).

Jun 16, 2009

- 09_0027

Conversion to Laser Mark for the LQFP Packages (Single Grades)

AD9804AJSTZ

Obsolete

AD9804AJSTZRL

Obsolete

Jul 13, 2016

- 16_0050

ADI Corporate Obsolescence Notice-2016 (Standard Products)

Jan 29, 2014

- 14_0014

ADI Corporate Obsolescence Notice-January 2014 (Standard Products)
