プロセッサとDSP

アナログ・デバイセズは、さまざまな一般的ニーズとアプリケーション固有ニーズに対応する、DSP、ミックスド・シグナル・コントロール・プロセッサ、組込みプロセッサ、アナログ・マイクロコントローラのポートフォリオを提供しており、その製品範囲は拡大を続けています。

All DSP Processors

  2つめ以降の並び替え条件は、“Shift” キーを押しながら選択してください。
SortOrderPart#Processor Product FamilyClock Input (max)
(Hz)
Device CoresMMACS (Max)Memory Supported ExternalGPIO pins
1ADSP-SC570-- 2---
2ADSP-SC573-- 2---
3ADSP-SC572-- 2---
4ADSP-SC571-- 2---
5ADSP-21573-- 2---
6ADSP-21571-- 2---
7ADSP-SC589 SHARC, SHARC + 450M 2 1800 LPDDR1 102
8ADSP-SC587 SHARC, SHARC + 450M 2 1800 LPDDR1 102
9ADSP-SC584 SHARC, SHARC + 450M 2 1800 LPDDR1 80
10ADSP-SC583 SHARC, SHARC + 450M 2 1800--
11ADSP-SC582 SHARC, SHARC + 450M 1 900 LPDDR1 80
12ADSP-21587 SHARC, SHARC + 450M 2 1800 LPDDR1 102
13ADSP-21584 SHARC, SHARC + 450M 2 1800 LPDDR1 80
14ADSP-21583 SHARC, SHARC + 450M 2 1800--
15ADSP-BF707 Blackfin, Blackfin+ 400M 1 800 DDR2/LPDDR (16-bit) 47
16ADSP-BF705 Blackfin, Blackfin+ 400M 1 800 DDR2/LPDDR (16-bit) 47
17ADSP-BF703 Blackfin, Blackfin+ 400M 1 800 DDR2/LPDDR (16-bit) 47
18ADSP-BF701 Blackfin, Blackfin+ 200M 1 400 DDR2/LPDDR (16-bit) 47
19ADSP-BF706 Blackfin, Blackfin+ 400M 1 800 DDR2/LPDDR (16-bit) 43
20ADSP-BF704 Blackfin, Blackfin+ 400M 1 800 DDR2/LPDDR (16-bit) 43
21ADSP-BF702 Blackfin, Blackfin+ 400M 1 800 DDR2/LPDDR (16-bit) 43
22ADSP-BF700 Blackfin, Blackfin+ 200M 1 400 DDR2/LPDDR (16-bit) 43
23ADSP-BF518F16 Blackfin 400M 1 800 Async, Mobile SDRAM, SDRAM 40
24ADSP-BF514F16 Blackfin 400M 1 800 Async, Mobile SDRAM, SDRAM 40
25ADSP-BF609 Blackfin 500M 2 2000 Async, DDR, LPDDR1 112
26ADSP-BF608 Blackfin 500M 2 2000 Async, DDR, LPDDR1 112
27ADSP-BF607 Blackfin 500M 2 2000 Async, DDR, LPDDR1 112
28ADSP-BF606 Blackfin 400M 2 1600 Async, DDR, LPDDR1 112
29ADSP-21477 SHARC 200M- 400- 16
30ADSP-21467 SHARC 450M- 900 DDR 16
31ADSP-BF506F Blackfin 400M 1 800- 35
32ADSP-BF592 Blackfin 400M 1 800- 32
33ADSP-21479 SHARC 266M- 532 Async, SDRAM 16
34ADSP-21478 SHARC 266M- 532 Async, SDRAM 16
35ADSP-BF504F Blackfin 400M 1 800- 35
36ADSP-BF504 Blackfin 400M 1 800- 35
37ADSP-21489 SHARC 450M- 900 Async, SDRAM 16
38ADSP-21488 SHARC 400M- 800 Async, SDRAM 16
39ADSP-21486 SHARC 400M- 800 Async 16
40ADSP-21469 SHARC 450M- 900 DDR 16
41ADSP-BF526C Blackfin 400M 1 800 Async, Mobile SDRAM, NAND Flash, SDRAM 48
42ADSP-BF526 Blackfin 400M 1 800 Async, Mobile SDRAM, NAND Flash, SDRAM 48
43ADSP-BF524C Blackfin 400M 1 800 Async, Mobile SDRAM, NAND Flash, SDRAM 48
44ADSP-BF524 Blackfin 400M 1 800 Async, Mobile SDRAM, NAND Flash, SDRAM 48
45ADSP-BF522C Blackfin 400M 1 600 Async, Mobile SDRAM, NAND Flash, SDRAM 48
46ADSP-BF522 Blackfin 400M 1 800 Async, Mobile SDRAM, NAND Flash, SDRAM 48
47ADSP-BF518 Blackfin 400M 1 800 Async, Mobile SDRAM, SDRAM 40
48ADSP-BF516 Blackfin 400M 1 800 Async, Mobile SDRAM, SDRAM 40
49ADSP-BF514 Blackfin 400M 1 800 Async, Mobile SDRAM, SDRAM 40
50ADSP-BF512 Blackfin 400M 1 800 Async, Mobile SDRAM, SDRAM 40
51ADSP-BF527C Blackfin 600M 1 1200 Async, Mobile SDRAM, NAND Flash, SDRAM 48
52ADSP-BF525C Blackfin 600M 1 1200 Async, Mobile SDRAM, NAND Flash, SDRAM 48
53ADSP-BF525 Blackfin 600M 1 1200 Async, Mobile SDRAM, NAND Flash, SDRAM 48
54ADSP-BF523C Blackfin 600M 1 1200 Async, Mobile SDRAM, NAND Flash, SDRAM 48
55ADSP-BF523 Blackfin 600M 1 1200 Async, Mobile SDRAM, NAND Flash, SDRAM 48
56ADSP-BF549 Blackfin 533M 1 1066 Async, DDR, Mobile DDR, NAND Flash 152
57ADSP-BF548 Blackfin 533M 1 1066 Async, DDR, Mobile DDR, NAND Flash 152
58ADSP-BF547 Blackfin 600M 1 1200 Async, DDR, Mobile DDR, NAND Flash 152
59ADSP-BF544 Blackfin 533M 1 1066 Async, DDR, Mobile DDR, NAND Flash 152
60ADSP-BF542 Blackfin 600M 1 1200 Async, DDR, Mobile DDR, NAND Flash 152
61ADSP-BF527 Blackfin 600M 1 1200 Async, Mobile SDRAM, NAND Flash, SDRAM 48
62ADSP-21375 SHARC 266M- 532 Async, SDRAM 16
63ADSP-BF539F Blackfin 533M 1 1066 Async, SDRAM 54
64ADSP-BF539 Blackfin 533M 1 1066 Async, SDRAM 54
65ADSP-BF538F Blackfin 533M 1 1066 Async, SDRAM 54
66ADSP-BF538 Blackfin 533M 1 1066 Async, SDRAM 54
67ADSP-21371 SHARC 266M- 532 Async, SDRAM 16
68ADSP-21369 SHARC 400M- 800 Async, SDRAM 16
69ADSP-21368 SHARC 400M- 800 Async, SDRAM 16
70ADSP-BF534 Blackfin 500M 1 1000 Async, SDRAM 48
71ADSP-BF537 Blackfin 600M 1 1200 Async, SDRAM 48
72ADSP-BF536 Blackfin 400M 1 800 Async, SDRAM 48
73ADSP-21366 SHARC 333M- 666 Async 16
74ADSP-21365 SHARC 333M- 666 Async 16
75ADSP-21364 SHARC 333M- 666 Async 16
76ADSP-21363 SHARC 333M- 666 Async 16
77ADSP-21362 SHARC 333M- 666 Async 16
78ADSP-TS203S TigerSHARC 500M- 4000 Async, SDRAM-
79ADSP-TS202S TigerSHARC 500M- 4000 Async, SDRAM-
80ADSP-TS201S TigerSHARC 600M- 4800 Async, SDRAM-
81ADSP-21261 SHARC 150M- 300 Async 16
82ADSP-21266 SHARC 200M- 400 Async 16
83ADSP-21262 SHARC 200M- 400 Async 16
84ADSP-BF533 Blackfin 600 1 1200 Async, Mobile SDRAM, SDRAM 16
85ADSP-BF532 Blackfin 400M 1 800 Async, Mobile SDRAM, SDRAM 16
86ADSP-BF531 Blackfin 400M 1 800 Async, Mobile SDRAM, SDRAM 16
87ADSP-BF561 Blackfin 600M 2 2400 Async, SDRAM 48
88ADSP-21992 ADSP-21xx 160M----
89ADSP-21991 ADSP-21xx 160M----
90ADSP-21990 ADSP-21xx 160M----
91ADSP-2191M ADSP-21xx 160M----
92ADSP-TS101S TigerSHARC 300M- 2400 Async, SDRAM-
93ADSP-2189N ADSP-21xx 80M----
94ADSP-2188N ADSP-21xx 80M----
95ADSP-2187N ADSP-21xx 80M----
96ADSP-2186N ADSP-21xx 80M----
97ADSP-2185N ADSP-21xx 80M----
98ADSP-2184N ADSP-21xx 80M----
99ADSP-2188M ADSP-21xx 75M----
100ADSP-2186M ADSP-21xx 75M----
101ADSP-2185M ADSP-21xx 75M----
102ADSP-2189M ADSP-21xx 75M----
103ADSP-2161 ADSP-21xx 25M----
