製品概要

機能と利点

  • Full featured evaluation board in conjunction with nanoDAC® motherboard (EVAL-MBnanoDAC-SDZ)
  • On-board references
  • Various link options
  • PC control in conjunction with Analog Devices, Inc., system demonstration platform (SDP)

製品概要

The EVAL-AD5680EBZ (Cypress based) is no longer available. Please use EVAL-AD5680DBZ (SDP based).


The EVAL-AD5680DBZ evaluation board is designed to help users quickly prototype new AD5680 circuits and reduce design time. The AD5680 operates from a single 4.5 V to 5.5 V supply.


For full specifications, see the AD5680 data sheet, which must be used in conjunction with user guide UG-989 when using the evaluation board.


The EVAL-AD5680DBZ evaluation board interfaces to the USB port of a PC via the SDP-B board. Software is available for download via the EVAL-AD5680DBZ product page that allows users to program the AD5680.

マーケット＆テクノロジー

対象となる製品

パッケージの内容

  • EVAL-AD5680DBZ evaluation board
  • EVAL-MBnanoDAC-SDZ motherboard

関連資料

  • すべてを表示 (2)
  • ユーザ・ガイド (1)
  • 評価用設計ファイル (1)
    • Document Type

    ソフトウェア

    評価用ソフトウェア

    ZIP
    332.19 M
    EVAL-AD5680DBZ Evaluation Software (Rev. 0)
    This software supports EVAL-AD5680DBZ.
    ZIP
    4.53 M
    EVAL-AD5680EBZ Software
    This is software for EVAL-AD5680EBZ which is no longer available.
